09931238D
Configuration of the equipment
Peltier control Single Cell
Peltier Controller
Power Cord, 3ea
Base Plate, 1ea
Wrench bolt. 2ea
Phillips round head screw with washer, 4ea
Coolant Hose, 1ea
Magnetic Stirrer, 1ea
Coolant, 2ea
Waste Basket for Coolant, 1ea
Waste Hose for Coolant, 1ea
Interface Cable (RS-232 or USB to RS-232), 1 each
Spare Fuse (AC 250V T5AL), 2ea
Temperature Probe, 1ea
1. Place the Lambda 465, Peltier Controller and Peltier Control Single Cell in a location that is
compatible with the required environmental conditions for the operation.
2. Open the lid of the coolant inlet on top of the Peltier Controller.
Figure 9 Lid of coolant inlet
3. Fill up the liquid coolant using the funnel.
CAUTION
ATTENTION
Make sure the instrument is turned off while installing this accessory.
Assurez-vous que l’instrument est é
teint lors de l’installation de cet
accessoire.
