Explorer Mini Electromagnetic compatibility
Electrical fast transient/
burst IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for input/output
lines
±2 kV for power
supply lines
±1 kV for input/output
lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge IEC 61000-4-5
±1 kV line(s) for power
supply line(s)
±2 kV for line(s) to
earth
±1 kV differential
mode
±2 kV common mode
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines IEC 61000-4-11
<5%
U
T
(>95% dip in
U
T
) for 0.5 cycle
40%
U
T
(60% dip in
U
T
) for 5 cycles
70%
U
T
(30% dip in
U
T
) for 25 cycles
<5%
U
T
(>95% dip in
U
T
) for 5 s
<5% UT (>95% dip in
UT) for 0.5 cycle
40% UT (60% dip in
UT) for 5 cycles
70% UT (30% dip in
UT) for 25 cycles
<5% UT (>95% dip in
UT) for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
the battery charger (PF2401A5SL) requires
continued operation during power mains
interruptions, it is recommended that the battery
charger (PF2401A5SL) be powered from an
uninterruptible power supply or a battery.
Power frequency (50/
60 Hz) magnetic field
IEC 61000-4-8
30 A/m 30 A/m
If image distortion occurs, it may be necessary to
position the battery charger (PF2401A5SL) further
from sources of power frequency magnetic fields
or to install magnetic shielding. The power
frequency magnetic field should be measured in
the intended installation location to assure that it is
sufficiently low.
Note:
U
T
is the a.c. mains voltage prior to application of the test level.
