Pfaff 1122 - Positioning the Needle in Centre of the Needle Hole

Adjustment
12 - 7
109-044
3
4
12.05.06 Positioning the needle in centre of the needle hole
Requirement
With the stitch length set at "0", the needles should enter the needle holes exactly in the
centre.
● Adjust needle bar frame 1 (screw 2) in accordance with the requirement.
● Turn needle bar 3 (screw 4) in accordance with the requirement.
Fig. 12 - 06
1
109-048
2
