Pfaff 1122 - Height of the Feed Dog

Adjustment
12 - 4
12.05.03 Height of the feed dog
Requirement
With the stitch length set at "0", at t.d.c. the feed dog should protrude ca. 1 mm over the
needle plate.
● Adjust holder 1 (screw 2) in accordance with the requirement.
Fig. 12 - 03
1 mm
1
2
