Care and maintenance
10 - 2
● Lubricate all bearings above the table top (see arrows) twice a week.
Turn the machine off! Danger of injury!
● Pull the knee lever out to the front and tilt the machine backwards.
● Lubricate all bearings below the table top (see arrows) twice a week.
Only use oil with a mean viscosity of 22.0 mm
2
/s at 40º C and a density of
0.865 g/cm
3
at 15º C!
We recommend PFAFF sewing machine oil, Order-No. 280-1-120 144.
Using both hands, set the machine into an upright position!
Danger of crushing between the machine and table top!
10.03 General lubrication
Fig. 10 - 02
1
2
3
0
