Adjustment
11 - 12
11
.04.11
Synchronizing the roller presser and feed dog
(only on machines with subcl. -4/01)
Requirement
The feed strokes of the roller presser and the feed dog must be equal.
Fig. 11 - 11
●
Adjust lever
1
(screw
2
) in accordance with the
requirement
.
+
-
2
1
50
52
