Adjustment
11 - 29
11
.05.06
Engaging lever
Requirement
With the needle bar at TDC and with control lever
3
at starting position, there must be a
clearance of approx.
0.3 mm
between bolt
4
and the outer diameter of control cam
5
.
Fig. 11 - 27
●
Bring the needle bar to TDC by turning the balance wheel.
●
Turn screw
1
(nut
2
) in accordance with the
requirement.
●
Carry out a check by tapping control lever
3
.
5
1
2
3
0.3 mm
5
3
4
67
69
