Adjustment
13 - 16
13
.05.14
Thread check spring, without subclass -900/56
Requirement
The mo
vement of thread c
hec
k spring
5
must be finished when the needle pointe enters
the material (=spring stroke of about
7 mm)
.
Fig. 11 - 14
●
Adjust stop
1
(screw
2
) according to
Requirement.
●
To adjust the pressure of the spring, turn screw
3
(screw
4
).
For technical reasons the length of the thread check spring stroke may vary
upwards or downwards a little.
4
5
1
3
2
7 mm
18
20
