Adjustment
13 - 33
13
.07 Parameter settings
(only on machines with Quick-EcoDrive and control unit P40ED)
● The selection of the user level and the alteration of parameters is described in the separate
instruction manual for the drive unit.
1 105 Speed for start backtack B, C 300 - 2000 600
110 Speed for end backtack B, C 300 - 2000 800
6 607 Speed max. B, C 300 - 6000 ▲
609 Cutting speed 1 B, C 60 - 300 180
7 700 Needle position 0 B, C 0 - 255 *
(needle reference position)
702 Needle position 1 (needle lowered) B, C 0 - 255 80
703 Needle position 2 (take-up lever raised) B, C 0 - 255 225
705 Needle position 5 (end cutting signal 1) B, C 0 - 255 100
706 Needle position 5 (start cutting signal 2) B, C 0 - 255 80
707 Needle position 9 (start thread tension B, C 0 - 255 195
release/start thread catcher)
722 Acceleration ramp B,C 1 - 60 45
723 Brake ramp B,C 1 - 60 40
734 Tact output A2 (thread trimming) B,C 001 - 009 0
760 Multiplier for the fixed value (200) for A, B, C 0 - 250 5
stitch count
799 Selected machine class C 1 - 4 2
▲
See Chapter 3 Specifications
*
Adjustment see Chapter 8.05 Basic position of the machine drive unit (in the machine
instruction manual)
13.07.01 Parameter list
Group
Parameter
Setting
range
Set value
User lever
Description
To Next Page
