Adjustment
21
15.04.16 Roller-presser pressure
Regel
The material must be fed reliably. No pressure marks may be made on the material.
● Adjust the presser foot pressure with screw 1 in accordance with the requirement.
Screw 1 is located under a cover.
If the presser foot pressure is low, the lowering speed of the presser foot can-
be increased with parameter „202“, see Chapter 15.07 Parameter settings.
Fig. 15 - 16
1
