Pfaff 1591

Adjustment
13
15.04.08 Height of the feed wheel (on the PFAFF 1591 and 1593)
Requirement
The feed wheel should protrude from the needle plate by tooth height (approx. 0.8 mm)
● Swing out the roller presser.
● Loosen screws 1.
● Adjust eccentric 3 (fastening screw accessible through hole 2) according to the require-
ment.
● Tighten screws 1.
Fig. 15 - 08
1
3
2
0,8 mm
