8 - 8
Installation and commissioning
● By pressing the corresponding +/- key select parameter "700".
8.09 Basic setting of the machine drive unit
(only on machines with Quick-Eco-Drive-Motor)
● Switch on the machine.
● Press TE/Speed key twice to call up the input mode.
2 x
● By pressing the corresponding +/- key call up parameter "798" and select value "II"
(service level "C"), see Chapter 12.07.01 Selecting the user level.
TE
101 on
ABCD
3333
TE
798 11
C
● By pressing the corresponding +/- key, call up parameter "800" (rotation direction of the
motor).
● By pressing the corresponding +/- key enter the value "1".
TE
800 1
A
C
