19
Installation and commissioning
Fig. 8 - 01
2
1
1
Loosen screws 1 and 2 and set the desired table-top height
Tighten screws 1 well.
Adj
ust the position of the pedal so that you can operate it comfortably and tighten screw 2.
●
●
●
8 Installation and commissioning
The machine must only be mounted and commissioned by qualified personnel!
All relevant safety regulations are to be observed!
If the machine is delivered without a table, it must be ensured that the frame
and the table top which you intend to use can hold the weight of the machine
and the motor. It must be ensured that the supporting structure is sufficiently
sturdy, including during all sewing operations.
8.01 Installation
The site where the machine is installed must be provided with suitable connections for the
electric current, see Chapter 3 Specifications.
It must also be ensured that the standing surface of the machine site is firm and horizontal,
and that sufficient lighting is provided.
The method of packaging used requires that the table top be lowered for trans-
port.
T
he f
ollowing is a description of how to adjust the height of the table top.
8.01.01 Adjusting the table-top height
