Care and maintenance
10.07 Parameter settings (only on machines with Quick-EcoDrive and control unit P40 ED)
The selection of the user level and the alteration of parameters is described in the sepa-
rate instruction manual for the drive unit.
●
10.07.01 Parameter list
Group Parameter Description User lever S
et
ting range
Set value
1
105 Speed for start backtackl B, C
300 - 2000 1200
110 Speed for end backtack B, C 300 - 2000 1200
6
606 Speed min. B
, C
30 - 300 180
607 Speed max. B, C
300 - 6000
▲
609 Cutting speed B, C 60 - 300 180
660 Bobbin thread control
0 = o
ff, 1 = thread monitor,
2 = reverse counter
A, B,
C
0 - 2 0
7
700 Needle position 0
Needle reference position
B
, C 0 -255 *
702 Needle position 1 (needle low
ered) B, C 0 - 255 90
703 Needle position 2 (tak
e-up lever raised B, C 0 - 255 236
705 End cutting signal B
, C 0 - 255 200
706 Start cutting signal B
, C 0 - 255 136
707 Needle position 9 (start thread tension
release/st
art thread catcher)
B, C 0 - 255 164
760 Multiplier for the fixed value (200)
stitch count
A,B,
C
0 - 250 5
799 Selected machine class C
1 - 3 1
8
800
Rotating direction of the motor C 0 - 1 1

See Chapter 3 Specifications
*
Adjustment see Chapter 8.05 Basic position of the machine drive unit.
Further parameters and the description for an internet update of the machine
software and reset /cold start of the machine can be found in the instruction
manual for the control panel.
