Pfaff 487

Sicherheit
8
Do not operate the machine without take-up lever guard 1!
Danger of injury by movement of take-up lever!
Do not operate the machine without finger guard 2!
Danger of injury by the needle!
Do not operate the mac
hine without belt guards 3 and 4!
Danger of injury by rot
ating drive belt!
Do not operate the machine without tilt lock 5!
Danger of crushing betw
een the sewing head and table top!
1.06 Danger warnings
A working area of 1 m must be kept free both in front of and behind the machi-
ne, so that easy access is possible at all times.
Never put your hands or fingers in the sewing area during sewing!
Danger of injury by the needle!
While set
ting or adjusting the machine do not leave any objects on the table nor
in the needle plate area! Objects may be trapped or flung out of the machine!
Fig. 1 - 01
3
1
2
5
4
