Pfaff powerline 2235 - Assembling the Top V-Belt Guard and Sewing Head Support

26
Installation
6.04 Assembling the top V-belt guard and sewing head support
● Attach guard belt 1 with screws 2.
● Insert sewing head support 3 into the hole in the table top.
Do not operate the machine with support 3! Danger from top-heavy
sewing head! Machine cannot fall over when tilted backwards!
Fig. 6 - 04
3
2
2
2
1
