Pfaff Powerline 2545 Adjustment Manual

Adjusting
42
Fig. 1 - 34
1.07.10 Position of the control curve
Regel
1. In the hand wheel position 305°, the catcher should just start with its movment.
2. When the thread trimmer attachment is in its idle state, a gap of 0.1 mm should exist
between the roller lever 5 and the control curve 1.
● Turn control curve 1 (screws 2) in accordance with rule 1.
● Adjust screw 3 (nut 4) in accordance with rule 2.
1
2
4
5
0,1 mm
3
