Pfaff Powerline 2545 - Balance Weight

Adjustment
7
1.05.02 Balance weight
Requirement
When the needle bar is positioned at b.d.c. (balance wheel position 180°) the largest ec-
centricity of the balance weight 1 should be at the top.
● Adjust balance weight 1 (screw 2) in accordance with the requirement.
1
2
1
2
Fig. 1 - 02
