Adjustment
8
1.05.03 Zero position of the unison feed
Requirement
When the stitch length is set at "0", the top and bottom feed dogs and the needle bar
should not make any feeding motion when the balance wheel is turned.
● Remove spring 1.
● Adjust crank 2 (screw 3) in accordance with the requirement.
● Replace the spring 1.
Fig. 1 - 03
1
3
2
