Pfaff Powerline 2545 Adjustment Manual

Adjusting
37
Fig. 1 - 29
1.07.05 Bottom transporter in sewing direction
Rule
At stitch length setting "0", the needle in sewing direction should pierce the middle of the
stitch hole in the bottom feed 1.
● Adjust bottom feed 1 (screw 2) in accordance with the rule.
● Mounting the needle-plate.
Of you mounte the needle-plate, make sure that the
ball-joint 3 of the knife 4 is in the cut-out
2
1
3
4
5
