Pfeiffer Vacuum FullRange PBR 260 User Manual

14
BG 5171 BEN / B (2017-02) PBR 260
WARNING
The supply common (pin 5) and the shield (pin 6) must be
connected at the supply unit with protective ground.
Incorrect connection, incorrect polarity or inadmissible supply
voltages can damage the gauge.

Reassemble the connector.

At the other end of the cable, mount a connector which is compatible with
your evaluation unit.

Plug in the connector.
Secure the connector on the gauge with
the screw (tightening torque ≤ 0.2 Nm).

Connect the other end of the cable to your evaluation unit.

Pfeiffer Vacuum FullRange PBR 260 Specifications

General

Brand	Pfeiffer Vacuum
Model	FullRange PBR 260
Category	Measuring Instruments
Language	English
