PG DRIVES TECHNOLOGY S-DRIVE - PROGRAMMING
SK76745/10
The parameter can be set to On or Off.
5.5 Low Battery Alarm Tone
This parameter sets the tone when the alarm is active. The parameter can be programmed to 0, 1, 2 or 3.
0 - No tone 1 - 2khz 2 - 1kHz 3 - 500hz
5.6 TruCharge Reset Level
This parameter sets the level to which the batteries must be charged in order to reset the TruCharge display. Each time the
controller is powered down it will store its TruCharge level. When the controller is powered up it will display the stored TruCharge
value and not allow the TruCharge display to rise above this level until the controller reads a value greater than the TruCharge
Reset Voltage (to Indicate the scooter has been charged). TruCharge Reset level is programmable between 200 deci-volts (Off)
and 450 deci-volts in steps of 0.1 volts.
The TruCharge reset level should be set to an appropriate value that indicates the vehicle has
been fully charged and thus the TruCharge display resets. PGDT takes no responsibility for
incorrect programming of this value.
6 Inhibit Parameters
6.1 Inhibit 1 Mode, Inhibit 1 Speed, Inhibit 1 Latch
For full details of these parameters refer to Chapter 2 section 6.1
6.2 Inhibit 2 Mode, Inhibit 2 Speed, Inhibit 2 Latch
For full details of these parameters refer to Chapter 2 section 4.11
6.3 Inhibit 3 Mode, Inhibit 3 Speed, Inhibit 3 Latch
For full details of these parameters refer to Chapter 2 section 4.11
6.4 Aux Output Mode
By connecting a relay to pin 11 of the 14-way connector in a similar fashion to the brake light configuration, as shown in the
Installation Chapter, the S Drive can be used to drive an Auxiliary Relay.
Aux Output Mode can be programmed to operate one of a range of functions. The Aux. Output Mode sets when the output will
be active. Pin 11 will be active depending on how Aux. Output Mode is programmed and Inhibit 2 being pulled low(0v).
There are 5 modes which can be set.
0 = Off (Aux Output mode not Active)
1 = Standby (Aux. Output is only Active in Standby)
2 = Drive (Aux Output is only Active in Forward and Reverse)
3 = Standby/Drive(Aux Output is only Active in Standby or Drive)
4 = Standby/Drive/Trip (Aux Output is active the entire time the controller is powered up.)
