S-DRIVE – APPENDIX - A PG DRIVES TECHNOLOGY
SK76745/10
Annex A - wiring guidance
The standard includes guidance on wiring sizes, but no requirements. PGDT provides its own guidance on wiring suitable for use
with S-Drive products.
Summary
Providing they are installed in accordance with the installation instructions and the recommendations in this document, S-Drive
products support conformity with the applicable requirements of ISO 7176-14:2009 of scooters in which they are used, with the
following exception, for which corrective action is in progress:
The tiller interface, charger/programmer and solenoid brake connectors presently have a UL 94 V-2 rating. The same rating
applies to the D50319 connector kit supplied for use with the S-Drive.
