PG DRIVES TECHNOLOGY S-DRIVE - PROGRAMMING
SK76745/10
Throttle Reference Test ISO Test Resistor
Battery - Section 5
Low Battery Flash Level Cable Resistance
Calibration Factor Low Battery Alarm
Low Battery Alarm Tone TruCharge Reset Level
Inhibit - Section 6
Inhibit 1 Mode, Operation & Speed Inhibit 2 Mode, Operation & Speed
Inhibit 3 Mode, Operation & Speed Aux Output mode
General - Section 7
Soft Stop Brake Time
Output Voltage Status Output Type
Diagnostic Flash Sequence Reverse Alarm
Reverse Alarm Tone Pulsed Reverse Alarm
Diagnostic Alarm Diagnostic Alarm Tone
Brake Disconnected Alarm Brake Disconnected Alarm Tone
Brake Fault Detect Brake Light
Push Too Fast Threshold Push Too Fast Time-out
Freewheel Enable Inhibit 2 Horn Input Enable
Motor - Section 8
Current Limit Min & Max Boost Drive Current & Time
Current Foldback Threshold, Time, Level Current Foldback Temperature
Motor Cooling Time Motor Compensation
Motor Stall Timeout Braking Current
Timed Foldback Braking Current Timed Foldback Speed
Enhanced Motor Compensation (Up) Enhanced Motor Compensation (Down)
Enhanced Motor Compensation (Up) Gain
Memory Functions - Section 9
Read System Log Clear System Log
Read Timer Clear Timer
1.4 Safety Fences
Limits (or fences) can be applied to some dealer accessible programmable parameters. These limits are known as safety fences
and are programmed by PGDT when the S-Drive is manufactured. The purpose of these fences is to prevent the scooter being
programmed to be too fast, or too severe in its acceleration or deceleration. The parameters which can have fences applied to
them are:
Forward Speed Reverse Speed
Acceleration (forward and reverse combined) Deceleration (forward and reverse combined)
Standard PGDT settings are 0 for the minimum fence value and 100 for the maximum fence value, meaning there is a full range
of adjustment. If you wish to apply different fence values, please contact PGDT.
