General| Form Factor | Mid Tower |
|---|---|
| Dimensions | 240 mm x 520 mm x 510 mm (W x H x D) |
| Material | Steel, Tempered Glass, Plastic |
| Radiator Support | Front: Up to 360mm, Top: Up to 360mm, Rear: Up to 140mm |
| Maximum GPU Length | 435 mm |
| Maximum CPU Cooler Height | 190 mm |
| Dust Filters | Front, Top, Bottom |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX |
| Expansion Slots | 7 |
| Front I/O Ports | 1x USB 3.1 Gen 2 Type C, 2x USB 3.0, Audio In/Out, Power Button, Reset Button |
| Cooling Support | Front: 3 x 120mm or 2 x 140mm, Top: 3 x 120mm or 2 x 140mm, Rear: 1 x 120mm or 140mm |
| Pre-installed Fans | Front: 2x 140mm, Rear: 1x 140mm |
| Weight | 13.5 kg |
