60 190CW9 LCD
General Product Specification
ʳ
3.3 Timing requirement
Factory Preset mode definition:
1. Perfect FOS while presenting all required timings.
2. Required timings need to be specified in User's Manual
Preset mode definition:
1. Need to support those timings.
2. Perfect FOS after auto adjustment.
User mode
1. Can save those timing that not in Preset mode and can be showed (not over
scalar or Panel spec.)
2. It needs to reserve the 12 timings space in memory size.
3.3.1 Mode storing capacity
Factory preset modes : 13
Preset modes : 50
User modes : 10
Note: 1. Screen displays perfect picture at 13 factory-preset modes.
2. Screen displays visible picture with OSD warning when input modes are the
48 preset modes
3.3.2 Factory preset modes
Factory modes and preset modes are defined in the enclosed timing table file
Please refer to 19W page.
˛ˌʳ˧˼˼˺ʳ
˴˵˿˸˲˅˃˃ˋ˃ˇ˃˄ˁ˿
Video timing mode (internal firmware support) ,
60Hz: 480p/720p/1080i/1080p
50Hz: 576p/720p/1080i/1080p
