Page #10 background imageLoading...
Page #10 background image
4
Channels
4.1
Install Channels
For more information, in Help, press the colour
key Keywords and look up Channel, Antenna
Installation or Channel, Cable Installation.
4.2
Channel Lists
About Channel Lists
After a channel installation, all channels appear on
the channel list. Channels are shown with their name
and logo if this information is available.
With a channel list selected, press the
arrows (up) or (down) to select a channel,
then press OK to watch the selected channel. You
only tune to the channels in that list when
using   or   keys.
Channel icons
After an Automatic Channel Update of the channel
list, newly found channels are marked with
a (star).
If you lock a channel, it will be marked with
a (lock).
Radio stations
If digital broadcasting is available, digital radio
stations are installed during installation. Switch to a
radio channel just like you switch to a TV channel. A
Cable (DVB-C) channel installation usually places
radio stations from channel number 1001 onwards.
This TV can receive digital television standard DVB. TV
may not work properly with some operators of digital
television, non-compliance with requirements of the
standard in full.
Open a Channel List
Next to the list with all channels, you can select a
filtered list or you can select one of the favourite lists
you created.
To open the current channel list…
1 - Press , to switch to TV.
2 - Press OK to open the current channel list.
3 - Press BACK to close the channel list.
To select one of the channel lists…
1 - With a channel list open on screen,
press OPTIONS.
2 - Select Select Channel List and press OK.
3 - In the list menu, select one of the available
channel lists and press OK.
Alternatively, you can select the list name at the top
of the channel list and press OK to open the list
menu.
Search for a Channel
You can search for a channel to find it in a long list of
channels.
The TV can search for a channel within one of the 2
main channel lists - the Antenna or Cable channel list.
To search for a channel…
1 - Press .
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Select Channel List and press OK.
5 - Select Filter Antenna Channels or Filter Cable
Channels and press OK.
6 - Select Search Channel and press OK to open
a text field.You can use the remote control keyboard
(if available) or the on-screen keyboard to enter text.
7 - Enter a number, a name or part of a name and
select Apply and press OK. The TV will search for
matching channel names in the list you selected.
Search results are listed as a channel list - see the list
name at the top. The search results disappear once
you select another channel list or close the list with
search results.
4.3
Channel List sorting
You can do channel list sorting with all channels. You
can set the channel list to show only TV channels or
only Radio stations. For Antenna/Cable channels you
can set the list to show the Free-to-Air or the
Scrambled channels.
To set a filter on a list with all channels…
1 - Press .
2 - Press OK to open the current channel list.
3 - Press OPTIONS.
4 - Select Select Channel List and press OK.
5 - Select Filter Antenna Channels or Filter Cable
Channels according to the list you want to filter, and
press OK.
6 - In the Options menu, select the filter you want
and press OK to activate. The name of the filter
appears as part of the channel list name on top of the
channel list.
10

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7503 and is the answer not in the manual?

Philips 55PUS7503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)139 cm
Screen format adjustments16:9, Zoom
Supported graphics resolutions3840 x 2160
Display refresh rates supported30 Hz, 60 Hz
Motion interpolation technology-
Audio decodersDTS
RMS rated power25 W
PC in (D-Sub)No
RF connector typeIEC
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity2
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)EasyLink
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)103 W
Package depth160 mm
Package width1360 mm
Package height890 mm
Package weight19300 g
User memory16 GB
Battery typeAA
Ambilight featuresAmbilight Music, Wall colour adaptive, Lounge mode
Google applicationsGoogle Music, YouTube
Picture enhancementUltra Resolutiuon, Micro Dimming Pro
Ambient lighting type3-sided
Annual energy consumption151 kWh
Sound enhancement technologyClear Sound, Smart Sound
Product colorSilver
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface300 x 200 mm
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG
Video formats supportedAVI, H.264, HEVC, MKV, MPEG1, MPEG2, MPEG4, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeDigital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Operating system versionNougat
Operating system installedAndroid
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna connector typeIEC75
Cables includedAC
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width780 mm
Depth (with stand)266.3 mm
Height (with stand)813.9 mm
Weight (with stand)16300 g
Depth (without stand)68.2 mm
Width (without stand)1244.2 mm
Height (without stand)741.5 mm
Weight (without stand)15500 g
