7 - Press (left) to go back one step or press to
close the menu.
4.4
Watching channels
Tune to a Channel
To start watching TV channels, press . The TV
tunes to the channel you last watched.
Switch Channels
To switch channels, press or .
If you know the channel number, type in the number
with the number keys. Press OK after you entered
the number to switch immediately.
If the information is available from the Internet, the TV
shows the current programme name and details
followed by the next programme name and details.
Previous channel
To switch back to the previously tuned channel,
press BACK.
You can also tune to channels from a Channel List.
Lock a Channel
Lock and Unlock a Channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
To lock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to lock.
4 - Press OPTIONS and select Lock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it. A
locked channel is marked with a (lock).
6 - Press (left) to go back one step or
press BACK to close the menu.
To unlock a channel…
1 - Press .
2 - Press OK to open the channel list. If necessary
change the channel list.
3 - Select the channel you want to unlock.
4 - Press OPTIONS and select Unlock
Channel and press OK.
5 - Enter your 4 digit PIN code if the TV asks for it.
6 - Press (left) to go back one step or
press BACK to close the menu.
If you lock or unlock channels in a channel list, you
only have to enter the PIN code just once until you
close the channel list.
For more information, in Help, press the colour
key Keywords and look up Child Lock for more
information.
Parental Rating
To prevent children from watching a programme not
suitable for their age, you can set an age rating.
Digital channels can have their programmes age
rated. When the age rating of a programme is equal to
or higher than the age you have set as age rating for
your child, the programme will be locked. To watch a
locked programme, you must enter the Parental
Rating code first.
To set an age rating…
1 - Press , select All Settings and press OK.
2 - Select Child Lock > Parental Rating and
press OK.
3 - Enter a 4-digit Child lock code. If you did not set
a code yet, select Set Code in Child Lock. Enter a
4-digit Child lock code and confirm. Now you can set
an age rating.
4 - Back in Parental Rating, select the age and
press OK.
5 - Press (left) repeatedly if necessary, to close
the menu.
To switch off the parental age rating, select None.
However, in some countries you must set an age
rating.
For some broadcasters/operators, the TV only locks
programmes with a higher rating. The parental age
rating is set for all channels.
Channel Options
Open Options
While watching a channel, you can set some options.
Depending on the type of channel you are watching
(analogue or digital) or depending on the TV settings
you made, some options are available.
To open the options menu…
1 - While watching a channel, press OPTIONS.
2 - Press OPTIONS again to close.
11

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7503 and is the answer not in the manual?

Philips 55PUS7503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)139 cm
Screen format adjustments16:9, Zoom
Supported graphics resolutions3840 x 2160
Display refresh rates supported30 Hz, 60 Hz
Motion interpolation technology-
Audio decodersDTS
RMS rated power25 W
PC in (D-Sub)No
RF connector typeIEC
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity2
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)EasyLink
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)103 W
Package depth160 mm
Package width1360 mm
Package height890 mm
Package weight19300 g
User memory16 GB
Battery typeAA
Ambilight featuresAmbilight Music, Wall colour adaptive, Lounge mode
Google applicationsGoogle Music, YouTube
Picture enhancementUltra Resolutiuon, Micro Dimming Pro
Ambient lighting type3-sided
Annual energy consumption151 kWh
Sound enhancement technologyClear Sound, Smart Sound
Product colorSilver
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface300 x 200 mm
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG
Video formats supportedAVI, H.264, HEVC, MKV, MPEG1, MPEG2, MPEG4, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeDigital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Operating system versionNougat
Operating system installedAndroid
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna connector typeIEC75
Cables includedAC
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width780 mm
Depth (with stand)266.3 mm
Height (with stand)813.9 mm
Weight (with stand)16300 g
Depth (without stand)68.2 mm
Width (without stand)1244.2 mm
Height (without stand)741.5 mm
Weight (without stand)15500 g
