Page #77 background image
24.3
Operating System
Android OS :
Android Nougat 7
24.4
Reception
• Aerial input : 75 ohm coaxial (IEC75)
• Tuner bands : Hyperband, S-Channel, UHF, VHF
• DVB : DVB-T2, DVB-C (cable) QAM
• Analogue video playback : SECAM, PAL
• Digital video playback : MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10), HEVC*
• Digital audio playback (ISO/IEC 13818-3)
• Satellite aerial input : 75 ohm F-type
• Input frequency range : 950 to 2150MHz
• Input level range : 25 to 65 dBm
• DVB-S/S2 QPSK, symbol rate 2 to 45M symbols,
SCPC and MCPC
• LNB : DiSEqC 1.0, 1 to 4 LNBs supported, Polarity
selection 14/18V, Band selection 22kHz, Tone burst
mode, LNB current 300mA max
* Only for DVB-T2, DVB-S2
24.5
Display Type
Diagonal screen size
• 123 cm / 49 inch
• 139 cm / 55 inch
Display resolution
• 3840 x 2160
24.6
Display Input Resolution
Video formats
Resolution — Refresh rate
• 480i - 60 Hz
• 480p - 60 Hz
• 576i - 50 Hz
• 576p - 50 Hz
• 720p - 50 Hz, 60 Hz
• 1080i - 50 Hz, 60 Hz
• 1080p - 24 Hz, 25 Hz, 30 Hz
• 2160p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz
Computer formats
Resolutions (amongst others)
• 640 x 480p - 60 Hz
• 800 x 600p - 60 Hz
• 1024 x 768p - 60 Hz
• 1280 x 768p - 60 Hz
• 1360 x 765p - 60 Hz
• 1360 x 768p - 60 Hz
• 1280 x 1024p - 60 Hz
• 1920 x 1080p - 60 Hz
• 3840 x 2160p - 24 Hz, 25 Hz, 30 Hz, 50 Hz, 60 Hz
24.7
Connectivity
TV Side
• Common Interface slot: CI+/CAM
• USB 1 - USB 2.0
• USB 2 - USB 3.0
• Headphones - Stereo mini-jack 3.5mm
• HDMI 1 in - ARC - MHL - Ultra HD - HDR
• HDMI 2 in - ARC - Ultra HD - HDR
TV Bottom
• Audio out - Optical Toslink
• Network LAN - RJ45
• YPbPr, L/R
• HDMI 4 in - ARC
• HDMI 3 in - ARC
• Antenna (75 ohm)
• Satellite tuner
24.8
Dimensions and Weights
49PUS7503
• without TV stand:
Width 1106.6 mm - Height 732.9 mm - Depth 68.2 mm
- Weight ± 13.4 kg
• with TV stand:
Width 1106.6 mm - Height 792.9 mm - Depth 266.3
mm - Weight ± 14.2 kg
55PUS7503
• without TV stand:
Width 1244.2 mm - Height 741.5 mm - Depth
68.2 mm - Weight ± 15.5 kg
• with TV stand:
Width 1244.2 mm - Height 813.9 mm - Depth
266.3 mm - Weight ± 16.3 kg
24.9
Sound
• Output power (RMS) : 25W
• Dolby Audio
• DTS-HD Premium Sound ™
77

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7503 and is the answer not in the manual?

Philips 55PUS7503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)139 cm
Screen format adjustments16:9, Zoom
Supported graphics resolutions3840 x 2160
Display refresh rates supported30 Hz, 60 Hz
Motion interpolation technology-
Audio decodersDTS
RMS rated power25 W
PC in (D-Sub)No
RF connector typeIEC
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity2
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)EasyLink
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)103 W
Package depth160 mm
Package width1360 mm
Package height890 mm
Package weight19300 g
User memory16 GB
Battery typeAA
Ambilight featuresAmbilight Music, Wall colour adaptive, Lounge mode
Google applicationsGoogle Music, YouTube
Picture enhancementUltra Resolutiuon, Micro Dimming Pro
Ambient lighting type3-sided
Annual energy consumption151 kWh
Sound enhancement technologyClear Sound, Smart Sound
Product colorSilver
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface300 x 200 mm
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG
Video formats supportedAVI, H.264, HEVC, MKV, MPEG1, MPEG2, MPEG4, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeDigital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Operating system versionNougat
Operating system installedAndroid
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna connector typeIEC75
Cables includedAC
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width780 mm
Depth (with stand)266.3 mm
Height (with stand)813.9 mm
Weight (with stand)16300 g
Depth (without stand)68.2 mm
Width (without stand)1244.2 mm
Height (without stand)741.5 mm
Weight (without stand)15500 g
