or both scheduled recordings.
To adjust the start or end time of a scheduled
recording…
1 - Press TV GUIDE.
2 - Press the colour key Recordings .
3 - At the top of the screen,
select Scheduled and press OK.
4 - In the list of scheduled recordings and reminders,
select the tab Recordings and press OK to view
the scheduled recordings only.
5 - Select the scheduled recording that conflicts with
another scheduled recording and press the colour
key Adjust Time .
6 - Select the start or end time and change the time
with the (up) or (down) keys.
Select Apply and press OK.
7 - Press BACK to close the menu.
Auto End Margin
You can set the time margin that the TV will add
automatically at the end of each scheduled recording.
To set the automatic end time margin…
1 - Press TV GUIDE.
2 - Press the colour key Recordings .
3 - Press OPTIONS and select Auto End
Margin and press OK.
4 - Press (up) or (down) and press OK to
set the time margin added to a recording
automatically. You can add up to 45 minutes to a
recording.
5 - Press BACK to close the menu.
Manual Recording
You can schedule a recording that is not linked to a
TV programme. You set the tuner type, channel and
the start and end time yourself.
To schedule a recording manually…
1 - Press TV GUIDE.
2 - Press the colour key Recordings .
3 - At the top of the screen,
select Scheduled and press OK.
4 - Press OPTIONS, select Schedule and
press OK.
5 - Select the tuner from where you want to record
and press OK.
6 - Select the channel to record from and press OK.
7 - Select the day of the recording and press OK.
8 - Set the start and end time of the recording. Select
a button and use the (up) or (down) keys to
set the hours and minutes.
9 - Select Record and press OK to schedule the
manual recording.
The recording will appear in the list of scheduled
recordings and reminders.
Watch a Recording
To watch a recording…
1 - Press TV GUIDE.
2 - Press the colour key Recordings .
3 - In the list of recordings, select the recording you
need and press OK to start watching.
4 - You can use the
keys (pause), (play), (rewind), (fast
forward) or (stop).
5 - To switch back to watch TV, press EXIT.
16.2
Pause TV
What You Need
You can pause a digital TV broadcast and resume
watching it a bit later.
To pause a TV programme you need…
• a connected USB Hard Drive formatted on this TV
• digital TV channels installed on this TV
• to receive channel information for the on screen TV
Guide
With the USB Hard Drive connected and formatted,
the TV continuously stores the TV broadcast you are
watching. When you switch to another channel, the
broadcast of the former channel is cleared. Also
when you switch the TV to standby the broadcast is
cleared.
You cannot use Pause TV when you are recording.
For more information, in Help, press the colour
key Keywords and look up USB Hard Drive,
installation.
Pause a Programme
To pause and resume a broadcast…
• To pause a broadcast, press (Pause). A progress
bar at the bottom of the screen appears briefly.
• To call up the progress bar, press (Pause) again.
• To resume watching, press (Play).
With the progress bar on screen, press (Rewind)
or press (Forward) to select from where you want
to start viewing the paused broadcast. Press these
keys repeatedly to change speed.
You can pause a broadcast for a maximum time span
of 90 minutes.
To switch back to the live TV broadcast,
64

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7503 and is the answer not in the manual?

Philips 55PUS7503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)139 cm
Screen format adjustments16:9, Zoom
Supported graphics resolutions3840 x 2160
Display refresh rates supported30 Hz, 60 Hz
Motion interpolation technology-
Audio decodersDTS
RMS rated power25 W
PC in (D-Sub)No
RF connector typeIEC
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity2
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)EasyLink
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)103 W
Package depth160 mm
Package width1360 mm
Package height890 mm
Package weight19300 g
User memory16 GB
Battery typeAA
Ambilight featuresAmbilight Music, Wall colour adaptive, Lounge mode
Google applicationsGoogle Music, YouTube
Picture enhancementUltra Resolutiuon, Micro Dimming Pro
Ambient lighting type3-sided
Annual energy consumption151 kWh
Sound enhancement technologyClear Sound, Smart Sound
Product colorSilver
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface300 x 200 mm
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG
Video formats supportedAVI, H.264, HEVC, MKV, MPEG1, MPEG2, MPEG4, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeDigital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Operating system versionNougat
Operating system installedAndroid
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna connector typeIEC75
Cables includedAC
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width780 mm
Depth (with stand)266.3 mm
Height (with stand)813.9 mm
Weight (with stand)16300 g
Depth (without stand)68.2 mm
Width (without stand)1244.2 mm
Height (without stand)741.5 mm
Weight (without stand)15500 g
