installation.
Installation
Before you can pause or record a broadcast, you
must connect and format a USB Hard Drive.
Formatting removes all files from the USB Hard Drive.
1 - Connect the USB Hard Drive to one of
the USB connections on the TV. Do not connect
another USB device to the other USB ports when
formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - When the TV is tuned to a digital TV channel,
press (Pause). Trying to pause will start the
formatting.
Follow the instructions on screen.
When the USB Hard Drive is formatted, leave it
connected permanently.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
Formatting
Before you can pause or record a broadcast, or store
apps, you must connect and format a USB Hard
Drive. Formatting removes all files from the USB Hard
Drive. If you want to record broadcasts with TV Guide
data from the Internet, you must setup the Internet
connection first before you install the USB Hard Drive.
Warning
The USB Hard Drive is formatted exclusively for this
TV, you cannot use the stored recordings on another
TV or PC. Do not copy or change recording files on
the USB Hard Drive with any PC application. This will
corrupt your recordings. When you format another
USB Hard Drive, the content on the former will be lost.
A USB Hard Drive installed on your TV will need
reformatting for use with a computer.
* Connect the USB Hard Drive with size less than 2TB.
To format a USB Hard Drive…
1 - Connect the USB Hard Drive to one of the USB
connections on the TV. Do not connect another USB
device to the other USB ports when formatting.
2 - Switch on the USB Hard Drive and the TV.
3 - Select Recordings if you want to perform Pause
TV and Recordings, otherwise, select Apps to store
apps. Follow the instructions on screen.
4 - All files and data will be removed after formatting.
5 - When the USB Hard Drive is formatted, leave it
connected permanently.
For more information, in Help, press the colour
key Keywords and look up Pause TV,
Recording, or Apps.
6.11
USB Keyboard
Connect
Connect a USB keyboard (USB-HID type) to enter text
on your TV.
Use one of the USB connections to connect.
Configure
Install the keyboard
To install the USB keyboard, switch on the TV and
connect the USB keyboard to one of
the USB connections on the TV. When the TV
detects the keyboard for the first time, you can select
your keyboard lay-out and test your selection. If you
select a Cyrillic or Greek keyboard layout first, you
can select a secondary Latin keyboard layout.
To change the keyboard layout setting when a layout
was selected…
1 - Press , select All Settings and press OK.
2 - Select General Settings and press (right) to
enter the menu.
3 - Select USB Keyboard Settings, and press OK to
start the keyboard setup.
29

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS7503 and is the answer not in the manual?

Philips 55PUS7503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Peak luminance ratio65 %
Display diagonal (metric)139 cm
Screen format adjustments16:9, Zoom
Supported graphics resolutions3840 x 2160
Display refresh rates supported30 Hz, 60 Hz
Motion interpolation technology-
Audio decodersDTS
RMS rated power25 W
PC in (D-Sub)No
RF connector typeIEC
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity2
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)EasyLink
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)103 W
Package depth160 mm
Package width1360 mm
Package height890 mm
Package weight19300 g
User memory16 GB
Battery typeAA
Ambilight featuresAmbilight Music, Wall colour adaptive, Lounge mode
Google applicationsGoogle Music, YouTube
Picture enhancementUltra Resolutiuon, Micro Dimming Pro
Ambient lighting type3-sided
Annual energy consumption151 kWh
Sound enhancement technologyClear Sound, Smart Sound
Product colorSilver
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface300 x 200 mm
Teletext standardsHyper-text
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG
Video formats supportedAVI, H.264, HEVC, MKV, MPEG1, MPEG2, MPEG4, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeDigital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Operating system versionNougat
Operating system installedAndroid
Wi-Fi standardsWi-Fi 5 (802.11ac)
Antenna connector typeIEC75
Cables includedAC
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width780 mm
Depth (with stand)266.3 mm
Height (with stand)813.9 mm
Weight (with stand)16300 g
Depth (without stand)68.2 mm
Width (without stand)1244.2 mm
Height (without stand)741.5 mm
Weight (without stand)15500 g
