Philips AG1000 - Vertical Movements of the P.u.arm; The Changer Mechanism; Operation of the ​ S Pindle​; Center Pen

on the SPINDLE/center pin and the stacker unit has been removed. After the control disc / command dial
is linked to the main axis, it will also rotate when the turntable/ platter is turned.
.
3. Vertical movements of the P.U.arm
Under the influence of the large long  CHUBBY tension spring (81) the lever tonge/ upper lifting strip (B
fig.8) is pulled in the >>>direction of the axis >>> of the control disc /command dial and rests against the
roller (123) on the cam disc. As When the control disc /command dial rotates, the roller rotates away
from the lever tab/ lifting strip, causing it to move >>>towards >>> the axis. As a result, the pick-up will
be pushed upwards by the lifting disc [82] . The movement/stroke is limited by the pin on the bottom
plate (73).
When at the  end of the revolution  of the control disc
When the roller 123 touches the lever plate/ lifting strip again, it is pushed back again, now in the
opposite direction against the force of the spring, and this gives the P.U, again the opportunity to fall
back descend, hereby helped by the pressure spring (85) under the pick up arm . The vertical
movements of the P.U.arm have now become clear. In order to prevent arbitrary/ random movements
of the P.U. arm when it is lifted off the, the disc ,the lever plate (H fig. 8) UNDER THE PRESSURE
SPRING 85 rests on a plastic disc which is mounted on the lifting disc.
4. The changer mechanism.
Under the influence of the SMALL skinny LONG tension spring (75)the change device/ insert LOWER
PLATE (74) is also pulled towards the control disc/command dial. The roller (68) on the changer presses
against the cam disc.
When the control disk rotates, there is a moment when the wheel/roller follows the profiled portion
of the disk, causing the change device to move in the direction of the command disk axis and then be
pushed back again. As a result of these movements the hinged part of the center pin is moved back and
forth.
P7b
5. Operation of the spindle / Center Pen.
As soon as the hinged part of the center pin (63) is moved by the changer device, all the discs are pushed
aside from the bottom side. The shoulder of the hinged pin, on which originally all the plates rested,
now fits in the extension of the pin, giving the bottom disc the opportunity to fall. The others rests on
the fixed part of the center pin. When the hinged part of the pin is pushed back by the mechanism, the
