Philips AG1000 - Brief Adjustment Description

Brief adjustment rule for the PHILIPS DISC changer
AG1000
.......................................................ERRATA.........................................................
V-2 - f: 1st part of second sentence must be;
Does it happen that the P.U. arm sometimes does not
goes up,
............................
IX - 1: With pos. (1) in this figure is not meant the
screw, as shown in the figure, but the stop bracket. The pivot point of this bracket is 2 cm to the left of
the screw (see fig. R14021).
............
X-1_
should be part of the first sentence: Check whether the free play in the change pin is too large.
..........................................
XII
Description of the error should be: The turntable continues to rotate after the P.U. arm has returned to
the start switch support.
.........................................................
BRIEF ADJUSTMENT DESCRIPTION
FOR THE PHILIPS
PLATE/disc CHANGER
AG 1000
41
