For the elimination of certain disruptions in the device, reference is also made to "Brief adjustment rule
for PHILIPS plate heat exchanger AG 1000M.
P11b
IX. Setting
the record changer.
The setting rule described below must be used when a changer has been disassembled for repair. It can
at the same time serve to check a changer if it does not meet the set requirements.
In the following, it is assumed that the following parts are not mounted:
-*** SEE ALSO 2.B. and p30 the two large LONG tension springs FIG 8
(81) and (75) - the horseshoe spring for the feeler (22)FIG 6 - the stop spring for the feeler (21)FIG 6 -
the pick-up head.
Furthermore, the device is moved by hand unless it is indicated that the mains voltage must be
connected.
Sequence
of the topics described:
1. The RECORD/plate printer. FIG 8 P22/P23
2. Adjust the lifting bracket and the RECORD FIG 6 18-22 P24/P25
3. Setting the STOP/lock position of the CONTROL disk.
4. Setting the start-stop mode.
5. Setting the stroke of the center pen.
6. Setting the REPEAT MECHANISM
7. Setting the PHONO SENSOR
8. Setting the speed. [NUMBER OF REVOLUTIONS]
9. Setting the ROLLER ON THE CONTROL DISC.
