a. Turn the screw 2 & 3 turns counterclockwise.
b. Now play a plate/DISC/RECORD and check whether the PU-ARM is up when
the needle enters the outlet groove (the needle can be set at 1/4 of the end of the plate).
c. Repeat this operation mentioned under a and b until the needle continues to run in the outlet
groove.
d. Now turn the screw 1/4 turn clockwise and check as indicated under b.
e. Repeat the procedure under d until PU arm goes up again when the needle enters the outlet
groove.
f. Now check the operation with different plates for normal as well as microgrovel. If it happens that
the PU-Arm sometimes goes up slightly, the screw should be turned 1/4 of a turn clockwise, with which
the mechanism is set.
3.
If the desired result can not be achieved with the adjustment described in point 2, then the adjustment
(2-VI) must be checked.
VI The arm does not raise at the end of a played, but continues to run in
the exit slot...........
1. The driver (1) on the steering hook
is bent and slides underneath the carrier (2), without touching it. The driver (1) must be bent slightly
upwards in such a way that the driver (2) is hit at about 1 mm from the bottom. See size in drawing.
48
