XIII
A. AFTER 9 PLATES ARE PLAYED, THE DEVICE
STOPS.
B. AFTER THE LAST PLATE IS PLAYED, THE DEVICE
CONTINUES TO REMAIN .
a. The angle between the steering rod (1)
and the plate printer (2) is too big. Slightly bend the arm until the angle between (1) and (2) is about 90º.
This bending should occur when the plate presser has the lowest position
taken. After adjusting the disc loader must not touch the alternating pin when the first is moved back
and forth.
To bend too far results in the error. will occur.
R14025
57
