Philips BDL3215E - BDL4225 E Model Specifications

User Manual BDL3215E / BDL4225E
47
3URGXFW6SHFLÀFDWLRQV%'/(
LCD Module
Diagonal: 42.02” / 106.731cm diagonal
Pixel Pitch: 0.4845 mm (H) x 0.4845 mm(V)
Resolution: 1920 x 1080 dots
Color: Over 16 million colors (depending on video card used)
Display Colors: 10bit-1.06 Billion colors
Brightness:
500cd /m
2
(typ.)
Contrast Ratio:
1400:1 (typ.)
Response time:
5ms (typ.)
Viewing Angle: 89° (typ.) @ CR>10
Design View Distance: 1300 mm
Frequency
Horizontal: 15.625 / 15.734, 31.5 - 91.1 kHz
Vertical: 50.0 / 58.0 - 85.0 Hz
Pixel Clock 25.0 MHz - 165.0 MHz
Viewable Size 930.24 mm x 523.26 mm
Input Signal
HDMI HDMI 19 Pin Digital Digital TMDS (with HDCP)
DVI-D DVI-D 24 Pin Digital RGB
DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA, SXGA60, UXGA*1, 1920 x 1080*1 (60Hz)
VGA 15pin Mini D-sub
Analog RGB
0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA, SXGA60, UXGA*1, 1920 x 1080*1 (60Hz)
Sync Separate: TTL level (Pos./Neg)
VGA(BNC)
BNC
(R,G,B,H,V)
Analog RGB
0.7 Vp-p/75ohm
VGA60, SVGA60, XGA60, WXGA, SXGA60, UXGA*1, 1920 x 1080*1 (60Hz)
Sync Separate: TTL level (Pos./Neg)
COMPONENT
BNC (Y,Cb/Pb,
Cr/Pr)
Component
Y: 1.0 Vp-p/75 ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD:1080i@60Hz, 1080p@60Hz, 720p@50Hz/60Hz, 576p@50Hz,
480p@60Hz, 576i@50Hz, 480i@60Hz
S-VIDEO Mini DIN 4 pin S-VIDEO
Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
VIDEO
BNC
RCA
Composite
1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
VGA 15pin Mini D-sub Analog RGB 0.7 Vp-p with 75 ohm terminated. Separate HV sync: TTL level (Pos./Neg)
VIDEO BNC Composite 1.0 Vp-p with 75 ohm terminated
AUDIO
AUDIO Input
RCA (L/R) x2
STEREO Mini
Jack
Analog RGB
Stereo L/R 0.5 Vrms
AUDIO Output RCA (L/R) Analog RGB Stereo L/R 0.5 Vrms
Speaker Speaker Jack 7W + 7W (8 ohm)
Control RS-232C In: 9 Pin D-sub
Power Supply 3.0 – 1.0 A @100 - 240 VAC, 50-60 Hz
Operational Environ-
ment
Temperature: 5 - 40 °C (landscape), 5 - 35 °C (portrait)
Humidity: 20 - 80 % (without condensation)
Altitude: 0 – 3000 m
Storage Environment
Temperature: -20 - 60 °C
Humidity:
10 - 90% (without condensation)/90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension
Net: 1021.8(w) x 662.7(H) x 250(D) mm
Gross: 1170(w) x 748(H) x 341(D) mm
Weight (without
stand)
Net: 21.8 kg
Gross: 28 kg
VESA Compatible arm mounting interface
200 mm x 200 mm & 200 mm x 400 mm (10Holes)
Complied Regulatory and Guidelines
UL60950-1/CSA C22.2 No. 60950-1/TUV/GS/EN60950-1
FCC-B/DOC-B/EN55022-B/EN55024/EN61000-3-2/EN61000-3-3/CE/GOST-R
