GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
2003-12-19
590
16
31
C.C.Liao
DELL P1230 M25P
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell P1230 130KHz
Go to cover page
4.2 Resolution
4.3 Brightness
Mode Resolution H. freq. / V. freq Standard
1. 640 x 480 31.469kHz/59.94Hz (VESA/60)
2. 640 x 480 43.269kHz/85.080Hz (VESA/85)
3. 800 x 600 53.674kHz/85.061Hz (VESA/85)
4. 1024 x 768 60.023kHz/75.029Hz (VESA/75)
5. 1024 x 768 68.677kHz/84.997Hz (VESA/85)
6. 1280 x 1024 79.976kHz/75.024Hz (VESA/75)
7. 1280 x 1024 91.15kHz/85.000Hz (VESA/85)
8. 1600 x 1200 93.75kHz/75.000Hz (VESA/75)
9. 1600 x 1200 106.25kHz/85.000Hz (VESA/85)
Color Temp
Brightnes
s
Contrast White Square Full white
control control (see fig-5)
CENTER MIN <0.1 FL
@9300°K
CENTER MAX 34 +4-2 FL 31 +3 / -2
FL
@6500°K
CENTER MAX 30 +4-2 FL
@5500°K
CENTER MAX 27 +4-2 FL
4.3.1 sRGB
Once press "sRGB " function on OSD, the luminance shall be changed
to and color temperature is matching to 6500 K, at white
square pattern.
4.4 Flag waving jitter less than 0.15mm.
4.5 Image size
4.5.1 Actual display size
The dimensions of the data area, measured along the picture
center of horizontal and vertical axis of the screen, are listed below:
(see FIG-1) (392+/-4 mm) X (294+/-4 mm)
4.5.2 Max scan size
Maximum active video size should be not smaller than mask
opening. The mask opening is 406.1 x 304.6 mm.
4.6 Image centering deviation
A-B and C-D , please see FIG-2
24 +5/-3ft-lb
4mm
