GENERAL PRODUCT SPECIFICATION(Continued)
8639 000 15121
2003-12-19
590
17
31
C.C.Liao
Go to cover page
202P Gs3 CM25
DELL P1230 M25P
61
22" CMTR-M25P-Dell-P1230
TYPE : 6L3P10/76
OEM : Dell 130KHz
4.7 Picture shift range
H-shift range : total .
V-shift range : total 15 mm.
4.8 Display dimension stability
Due to brightness : 1.0 %
Due to aging : 1.0 %
Due to mains voltage : 1.0 %
Dynamic :
4.9 Geometric distortions
Pincushion, trapezoid, parallelogram, rotation and other
various distortions must remain within the limits to tolerance
4.10 Picture tilt
mm (see FIG-3)
User adjust range for tilt:
as
in FIG-4.
20 mm
0.5mm
Top or bottom : < 1.5mm
Top + bottom : < 3.0mm
Left or right : < 2.0mm
Left + right : < 3.5mm
Tilt :
(For all preload modes, the entire image should be displayed
0.5
Inside the bezel.)
1mm ( 0.5 )
Short segments : 0.5mm (Line straightness 50mm)
Long segments : No greater than 1% of line
segment length.
4.11 Image non-linearity (12 x 9 grid)
Max. - Min.
--------------- x 100 %
Mean
Horizontal & vertical non-linearity (B) 10 %(all other
8 % (Prime mode
For any two adjacent horizontal & vertical blocks: (B)
8 %(all other preset modes 30 - 130 kHz)
5 %(Prime mode 93.75 kHz)
preset modes 30 - 130 kHz)
93.75 kHz)
