D238 ZENER DIODE DZ-6.8BSCT265 or NDTC0DZ6R8BS 4835 130 38027
ZENER DIODE MTZJT-776.8C QDTC0MTZJ6R8 4835 130 37881
D239 ZENER DIODE DZ-9.1BSCT265 or NDTC0DZ9R1BS 4835 130 38028
ZENER DIODE MTZJT-779.1C QDTC0MTZJ9R1 4835 130 37506
D242 ZENER DIODE DZ-27BSDT265 or NDTD00DZ27BS 9965 000 25454
ZENER DIODE MTZJT-7727D QDTD00MTZJ27 9965 000 25455
D243 RECTIFIER DIODE 1N4005 or NDQZ001N4005 4835 130 37047
RECTIFIER DIODE 1N4005 NDWZ001N4005 4835 130 37047
D247 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS 4835 130 38031
ZENER DIODE MTZJT-7718B QDTB00MTZJ18 4835 130 37784
D248 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS 4835 130 38061
ZENER DIODE MTZJT-7733D QDTD00MTZJ33 4835 130 37694
D250 ZENER DIODE DZ-3.6BSBT265 or NDTB0DZ3R6BS 9965 000 25456
ZENER DIODE MTZJT-773.6B QDTB0MTZJ3R6 4835 130 38076
ICS
●
IC201 IC, VIDEO SW STV6618 NSZBA0RSS221 9965 000 25458
●
IC202 IC, SW NJM2285-TE1 QSZBA0TJR077 9965 000 25459
●
IC203 IC, AUDIO SW TC4052BF(EL) or QSZBA0TTS096 4835 209 47641
IC, AUDIO SW BU4052BCF-E2 or QSZBA0TRM024 4835 209 47639
IC, AUDIO SW CD4052BCSJX or NSZBA0TF3079 9965 000 23425
IC, AUDIO SW CD4052BNSR NSZBA0TTY091 4835 209 47638
●
IC206 IC, AUDIO DAC UDA1334BTS NSZBA0TPH026 9965 000 25460
●
IC208 IC, OP AMP MC33078DR2 NSZBA0TN2004 4835 209 47637
●
IC209 IC, OP AMP MC33078DR2 NSZBA0TN2004 4835 209 47637
●
IC211 IC, SW NJM2285-TE1 QSZBA0TJR077 9965 000 25459
●
IC212 IC, SW TC4053BF(EL.N) or QSZBA0TTS131 4835 209 47549
IC, SW BU4053BCF-E2 or QSMDA0TRM010 CK31 992 R
IC, SW CD4053BCSJX or NSZBA0TF3071 4835 209 47611
IC, SW CD4053BNSR NSZBA0TTY093 4835 209 47611
●
IC213 IC, SW TC4053BF(EL.N) or QSZBA0TTS131 4835 209 47549
IC, SW BU4053BCF-E2 or QSMDA0TRM010 CK31 992 R
IC, SW CD4053BCSJX or NSZBA0TF3071 4835 209 47611
IC, SW CD4053BNSR NSZBA0TTY093 4835 209 47611
●
IC218 IC, EEPROM CAT24WC02JI or NSZBA0SBG001 4835 209 47596
IC, EEPROM BR24L02F-WE2 QSZBA0TRM068 4835 209 47636
●
IC221 IC, FIP DRIVER PT6313-S-TP NSZBA0TG2006 9965 000 19575
IC225 IC, FIP 7-BT-300GN TVFD1C0FT043 9965 000 25463
●
IC226 IC, MTS/SAP/Hi-Fi AUDIO PROCESS/Hi-
Fi HEAD AMP LA72670BM-MPB-E
QSZBA0RSY039 4835 209 47634
●
IC227 IC, VIDEO/AUDIO/SIGNAL PROCESS/
HEAD AMP LA71205M-MPB-E
QSZBA0RSY037 4835 209 47629
●
IC228 IC, SYSTEM CONTROL MICROPRO-
CESSOR MN101D08DEG1
QSZAB0RMS027 9965 000 25464
●
IC229 IC, +12V SWITCHING RTQ035N03 TR QF2ZTQ035N03 9965 000 25465
●
IC230 IC, -5V SWITCHING RTQ045N03 TR QF2ZTQ045N03 9965 000 25466
IC231 IC, SHUNT REGULATOR KIA431A-AT or NSZBA0TJY018 4835 209 47618
IC, SHUNT REGULATOR TL431A-TA NSZBA0TQ2003 4835 209 47621
IC232 IC, SHUNT REGULATOR KIA431A-AT or NSZBA0TJY018 4835 209 47618
IC, SHUNT REGULATOR TL431A-TA NSZBA0TQ2003 4835 209 47621
IC233 IC, SHUNT REGULATOR KIA431A-AT or NSZBA0TJY018 4835 209 47618
IC, SHUNT REGULATOR TL431A-TA NSZBA0TQ2003 4835 209 47621
●
IC234 IC, AUDIO ADC UDA1361TS NSZBA0TPH025 9965 000 25468
COILS
L205 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L206 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L207 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L208 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L210 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L211 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L214 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L215 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L217 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101 4835 157 57369
L218 CHOKE COIL 47µH-K or LLBD00PKV007 4835 157 58208
CHOKE COIL 47µH-K or LLBD00PKV005 4835 157 58208
CHOKE COIL 47µH-K LLBD00PKT001 4835 157 58208
L220 INDUCTOR 47µH-K-5FT LLARKBSTU470 4835 157 57375
L221 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L222 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L224 CHOKE COIL 47µH-K or LLBD00PKV007 4835 157 58208
CHOKE COIL 47µH-K or LLBD00PKV005 4835 157 58208
Ref. No. # Description ID No. Part No.
CHOKE COIL 47µH-K LLBD00PKT001 4835 157 58208
L226 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L227 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101 4835 157 57369
●
L228 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
L1351 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47 4835 157 58018
TRANSISTORS
Q201 MUTE-CTL BC547-B-AT NQSB000BC547 9965 000 25523
Q202 MUTE-CTL BC557-B-AT NQSB000BC557 9965 000 25473
Q203 P-ON RESET KRA303-RTK "PNP" NQ1Z00KRA303 9965 000 25474
Q204 AUDIO MUTE BC337-25-AT NQS8000BC337 9965 000 25475
Q205 AUDIO MUTE BC337-25-AT NQS8000BC337 9965 000 25475
Q206 P-ON RESET BC557-B-AT NQSB000BC557 9965 000 25473
Q207 AMP BC547-B-AT NQSB000BC547 9965 000 25523
Q208 AMP BC557-B-AT NQSB000BC557 9965 000 25473
Q209 BUFFER BC557-B-AT NQSB000BC557 9965 000 25473
Q210 SWITCHING BC557-B-AT NQSB000BC557 9965 000 25473
Q213 BUFFER BC547-B-AT NQSB000BC547 9965 000 25523
Q214 BUFFER BC547-B-AT NQSB000BC547 9965 000 25523
Q215 BUFFER BC557-B-AT NQSB000BC557 9965 000 25473
Q216 MUTE-ON KRC103M "NPN" or NQSZ0KRC103M 4835 130 47909
MUTE-ON BA1F4M-T QQSZ00BA1F4M 4835 130 48204
Q217 MUTE-ON KRC103M "NPN" or NQSZ0KRC103M 4835 130 47909
MUTE-ON BA1F4M-T QQSZ00BA1F4M 4835 130 48204
Q218 MUTE-ON KRC103M "NPN" or NQSZ0KRC103M 4835 130 47909
MUTE-ON BA1F4M-T QQSZ00BA1F4M 4835 130 48204
Q219 BUFFER BC557-B-AT NQSB000BC557 9965 000 25473
Q220 BUFFER BC547-B-AT NQSB000BC547 9965 000 25523
Q221 INVERTER BC557-B-AT NQSB000BC557 9965 000 25473
Q222 BUFFER BC557-B-AT NQSB000BC557 9965 000 25473
Q223 BUFFER BC547-B-AT NQSB000BC547 9965 000 25523
Q224 BUFFER BC557-B-AT NQSB000BC557 9965 000 25473
Q226 SWITCHING KTA1266(GR) "PNP" or NQS40KTA1266 4835 130 47422
SWITCHING 2SA1015-GR(TPE2) "PNP" QQS102SA1015 4835 130 47399
Q227 BIAS OSC KTC3203(Y) "NPN" or NQSY0KTC3203 4835 130 48126
BIAS OSC 2SC2120-Y(TPE2) "NPN" QQSY02SC2120 4835 130 48047
Q228 SWITCHING D-REC-OFF KRA103M
"PNP" or
NQSZ0KRA103M 4835 130 47907
SWITCHING D-REC-OFF BN1F4M-T QQSZ00BN1F4M 4835 130 48201
●
Q229 SWITCHING PB-ON RN1511(TE85R) or QQ2Z00RN1511 9965 000 12361
SWITCHING PB-ON FMG4A T148 QQ2Z000FMG4A 9965 000 16623
Q231 RESET KRC108M "NPN" NQSZ0KRC108M 4835 130 48057
Q232 BUFFER KTA1266(GR) "PNP" or NQS40KTA1266 4835 130 47422
BUFFER 2SA1015-GR(TPE2) "PNP" QQS102SA1015 4835 130 47399
Q233 BUFFER KTC3193(Y) "NPN" NQSY0KTC3193 4835 130 48016
Q235 RESET KTA1267(Y) "PNP" or NQSY0KTA1267 4835 130 47913
RESET KTA1267(GR) "PNP" or NQS10KTA1267 4835 130 47913
RESET 2SA1175(J) "PNP" or QQSJ02SA1175 4835 130 47645
RESET 2SA1175(H) "PNP" or QQSH02SA1175 4835 130 47645
RESET 2SA1175(F) "PNP" QQSF02SA1175 4835 130 47645
Q240 TAKEUP REEL SENSOR PT204-6B-12 or NPWZT2046B12 4835 130 48222
TAKEUP REEL SENSOR MID-32A22F NPWZ1D32A22F 4835 130 48231
Q242 LED DRIVE KTC3199(BL) "NPN" or NQS50KTC3199 4835 130 47914
LED DRIVE 2SC2785(K) "NPN" or QQSK02SC2785 4835 130 47722
LED DRIVE 2SC1815-BL(TPE2) "NPN" QQS202SC1815 4835 130 47358
Q243 LED DRIVE KTC3199(BL) "NPN" or NQS50KTC3199 4835 130 47914
LED DRIVE 2SC2785(K) "NPN" or QQSK02SC2785 4835 130 47722
LED DRIVE 2SC1815-BL(TPE2) "NPN" QQS202SC1815 4835 130 47358
Q245 LED DRIVE KTC3199(BL) "NPN" or NQS50KTC3199 4835 130 47914
LED DRIVE 2SC2785(K) "NPN" or QQSK02SC2785 4835 130 47722
LED DRIVE 2SC1815-BL(TPE2) "NPN" QQS202SC1815 4835 130 47358
Q246 -FL SWITCHING BC557-B-AT NQSB000BC557 9965 000 25473
Q247 SWITCHING KRC103M "NPN" or NQSZ0KRC103M 4835 130 47909
SWITCHING BA1F4M-T QQSZ00BA1F4M 4835 130 48204
Q248 SWITCHING BC547-B-AT NQSB000BC547 9965 000 25523
Q250 SWITCHING BC547-B-AT NQSB000BC547 9965 000 25523
Q251 SWITCHING KRC103M "NPN" or NQSZ0KRC103M 4835 130 47909
SWITCHING BA1F4M-T QQSZ00BA1F4M 4835 130 48204
Q252 +5V SWITCHING 2SK2095N QFWZ2SK2095N 9965 000 25476
Q253 +9V SWITCHING KTC3198(Y) "NPN" or NQSY0KTC3198 4835 130 47946
Ref. No. # Description ID No. Part No.
To Next Page
