Philips DVDR600VR/37 - Front CBA Top;Bottom View <VCR Section

1-12-31
1-12-32
Front CBA Top View < VCR Section > Front CBA Bottom View < VCR Section >
BE9480F01022D
FRONT CBA PARTS LOCATION GUIDE
Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position
C801 B-3 C811
C-1
C820
C-3
IC801
C-2
Q805
C-3
C802 B-3 C812
C-1
C821
C-2
Q806
C-1
C803
C-3
C813 C-1 C822
C-2
L801
B-2
Q807
C-1
C804
C-3
C814 B-1 L802
B-3
C805
B-2
C815 B-1 CN801 B-3 L803
B-3
R801
C-3
C806
B-2
C816
B-1
R802
C-3
C807
B-2
C817
C-1
D801
B-2
Q801
C-3
R803
B-2
C809
C-2
C818
C-1
D802 C-2 Q802
C-3
R804
B-2
C810 C-1 C819 C-3 D803 C-2 Q803 C-3 R805 B-2
CAPACITORS
RESISTORS
TRANSISTORSCAPACITORS
CONNECTOR
CAPACITORS
COILS
TRANSISTORSDIODES
IC
Ref No. Position Ref No. Position Ref No. Position Ref No. Position
R806
C-3
R815 C-1 R826
C-1
R836
C-3
R807
C-3
R816 C-1 R827
C-1
R808 C-3 R817
C-1
R828 C-1 SW801
C-1
R809 C-3 R818 C-1 R829 C-1 SW802
C-1
R810 C-3 R819
B-1
R830 B-2 SW803
C-1
R811 C-3 R820
B-1
R831
C-1
R812 C-3 R822
C-1
R832 C-2 X801
C-2
R813 C-3 R823 C-1 R833
C-3
R814 C-1 R825 C-1 R835 B-2 FIP801 B-1
RESISTORSRESISTORS
MISCELLANEOUS
SWITCHES
CRYSTAL OSCILLATOR
RESISTORSRESISTORS
