DECK EXPLODED VIEWS
Deck Mechanism View 1
Mark Description
Floil G-684G or Multemp MH-D
(Blue grease)
SLIDUS OIL #150
B12
B492
B11
B571
B37
Some Ref. Numbers are not in sequence.
B126
B8
B121
B426
B560
L1450
L1450
L1466
B501
Chassis Assembly
Top View (Lubricating Point)
Chassis Assembly
Bottom View (Lubricating Point)
