Philips FW-C380 - LOCATION OF PRINTED CIRCUIT BOARDS; VERSION VARIATIONS:

1-2
LOCATION OF PRINTED CIRCUIT BOARDS
ETF7
BOARD
MAINS
BOARD
POWER
BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
CD KEY BOARD
FRONT
BOARD
KARAOKE
BOARD
AF9
BOARD
HEADPHONE
BOARD
CD
BOARD
/21 /22 /30 /34 /37
Aux in /CDR in xxxxx
Line Out
Surround Out
Subwoofer Out xxxxx
Digital Out xxxxx
Matrix Surround
CD Text
Dolby B
RDS x x
News x x
Dolby Pro Logic (DPL)
Incredible Surround xxxxx
Karaoke Features x
Voltage Selector x
ECO Power Standby (Clock Display Off) x x x
ECO6 Tuner Board - Systems Non-Cenelec x x x x
ECO6 Tuner Board - Systems Cenelec x
Center/Surround Channel
Note: 3CDC-LC-MB Module is mechanically the same as 3CDC-LC Module except the schematics, layouts & electrical
parts list related to the CDC Board.The CDC Board (recognized by 12NC : 3103 303 34522 printed on the Board)
is introduced as an alternative to supplement for the shortage of Servo IC TDA7073A.
VERSION VARIATIONS:
Type /Versions: FW-C380
Features &
Board in used:
