Chapter 1: Overview
Table 1-9: IP Address Assignments for Non-routed ICN Subnet
Device Types
(with Non-routed Subnet)
IP Addresses
Subnet Mask:
255.255.248.0
Default
Gateway
Network Subnet Address 172.31.n.0 Left Blank (0.0.0.0)
Reserved for Routed Solution 172.31.n.1 - 3
Reserved for Service PC 172.31.n.4 - 9 IP Address of DBS or
M3150 Information Center
Network Switches and Remote
Client Infrastructure (i.e.,
Remote Client Router)
172.31.n.10 - 102 IP Address of DBS or
M3150 Information Center
Reserved for Future Use 172.31.n.103 - 255
1.4/2.4 Ghz ITS APCs 172.31.(n+1).0 - 63 IP Address of DBS or
M3150 Information Center
Reserved 172.31.(n+1).64 - 127
Reserved 172.31.(n+1).128 - 255
1.4GHz AP Static Range 172.31.(n+2).0 - 127 IP Address of DBS or
M3150 Information Center
Bootp/DHCP Server Range 2 for
1.4Ghz APs (configured in APC)
172.31.(n+2).128 - 255 IP Address of DBS or
M3150 Information Center
Database server (NIC 1) 172.31.(n+3).0
Application Server (NIC 1) 172.31.(n+3).16 - 31 IP Address of DBS or
M3150 Information Center
Information Centers (NIC 1) 172.31.(n+3).32 - 63 IP Address of DBS or
M3150 Information Center
Information Center Clients 172.31.(n+3).64 - 95 IP Address of DBS or
M3150 Information Center
Printers (Set by BootP in DBS) 172.31.(n+3). 96 - 127 IP Address of DBS or
M3150 Information Center
Reserved 172.31.(n+3).128 - 255
Bedside Monitors/Devices
(Wired & ISM 2.4 GHz Wireless)
172.31.(n+4).0 - 255 IP Address of DBS or
M3150 Information Center
Reserved for Future Use 172.31.(n+5).0 - 255
Bootp/DHCP Server Range 1 for
1.4/2.4 GHz ITS Transceivers/
Bedsides (config in APC)
172.31.(n+6).0 - 255 IP Address of DBS or
M3150 Information Center
Reserved for Future Use 172.31.(n+7).0 - 254
Network broadcast address 172.31.(n+7).255
