Philips L01.1E - Spare Parts List; Mono carrier; Various

Spare Parts List
GB 67L01.1E 10.
10. Spare Parts List
Mono carrier
Various
0127  4822 265 11253 Fuse holder
0129 3139 120 10151 NTC holder
0136 4822 492 70788 Fix IC
0137 3139 121 27001 Spring
0138 4822 492 70788 Fix IC
0139 3122 121 24785 Spring for bracket
0141 4822 492 70788 Fix IC
0150
 3104 311 02201 4P 560mm
0152 3104 301 08411 6P 480mm
0152 3104 301 09421 6P 400mm
0153 3104 301 08381 Cable assy
0153 3104 311 00681 5P 560mm
0211
 4822 265 20723 2P
0212
 4822 267 10774 2P male (red)
0219 2422 025 15849 6P male
0220 4822 265 30735 5P
0221
 4822 267 10966 2P
0222
 2422 025 10646 2P male
0224 4822 267 10982 2P
0235 2422 025 16745 Scart 42P female
0235 4822 267 10771 Scart 42P female
0243 2422 025 04854 6P female
0244 4822 265 30735 5P
0245 2422 025 04854 6P female
0250 4822 265 11606 3P
0251 2422 025 15849 6P male
0254
 2422 500 80053 9P female
0265
 4822 267 10748 3P
0267 4822 267 10735 3P
0268 4822 267 10735 3P
0278 4822 267 10735 3P
1000
 2422 542 90111 TUN V+U PLL IEC BGDK B
1000
 3139 147 17401 Tuner UR1316R/A I -3
1002 4822 242 81436 Filter OFWK3953M
1003 4822 242 11055 Filter OFWK6289K
1004 2422 549 44341 Filter OFWK9656M
1200 4822 242 81712 TPWA04B
1201 4822 242 10315 TPT02B-TF21
1400
 2422 132 07478 Relay 5A 10V
1500
 2422 086 10914 Fuse 4A 250V
1515
 2422 132 07444 Relay 5A 12V
1515
 4822 280 10367 Relay 5A 12V
1660 2422 543 01203 Chrystal 12MHz
1831 4822 242 10769 Chrystal 18.432MHz

2001 5322 122 32658 22pF 5% 50V
2002 5322 122 32658 22pF 5% 50V
2003 4822 122 33177 10nF 20% 50V
2004 4822 126 13751 47nF 10% 63V
2005 4822 124 40248 10mF 20% 63V
2006 4822 124 80791 470mF 20% 16V
2007 4822 126 14585 100nF 10% 50V
2008 4822 124 40207 100mF 20% 25V
2009 5322 122 32654 22nF 10% 63V
2010 5322 126 10511 1nF 5% 50V
2101 4822 122 33172 390pF 5% 50V
2102 4822 122 33172 390pF 5% 50V
2103 2020 552 96305 4U7 20% 10V
2104 4822 122 33172 390pF 5% 50V
2105 4822 122 33172 390pF 5% 50V
2106 2020 552 96305 4U7 20% 10V
2107 4822 122 33172 390pF 5% 50V
2108 4822 122 33172 390pF 5% 50V
2109 2020 552 96305 4U7 20% 10V
2110 4822 122 33172 390pF 5% 50V
2111 4822 122 33172 390pF 5% 50V
2112 2020 552 96305 4U7 20% 10V
2113 5322 122 32658 22pF 5% 50V
2114 5322 122 32658 22pF 5% 50V
2115 5322 122 32658 22pF 5% 50V
2116 5322 122 32658 22pF 5% 50V
2117 5322 122 32658 22pF 5% 50V
2118 5322 122 32658 22pF 5% 50V
2120 5322 122 32658 22pF 5% 50V
2131 4822 122 33172 390pF 5% 50V
2132 4822 122 33172 390pF 5% 50V
2133 2020 552 96305 4U7 20% 10V
2134 4822 122 33172 390pF 5% 50V
2135 4822 122 33172 390pF 5% 50V
2136 2020 552 96305 4U7 20% 10V
2137 4822 122 33172 390pF 5% 50V
2138 4822 122 33172 390pF 5% 50V
2139 2020 552 96305 4U7 20% 10V
2140 4822 122 33172 390pF 5% 50V
2141 4822 122 33172 390pF 5% 50V
2142 2020 552 96305 4U7 20% 10V
2143 5322 122 31863 330pF 5% 63V
2144 5322 122 31863 330pF 5% 63V
2145 5322 122 32658 22pF 5% 50V
2147 5322 122 32658 22pF 5% 50V
2151 5322 122 31863 330pF 5% 63V
2152 2020 552 96305 4U7 20% 10V
2153 5322 122 31863 330pF 5% 63V
2154 2020 552 96305 4U7 20% 10V
2161 4822 124 12392 47mF 20% 16V
2171 4822 126 13682 100pF 5% 1kV
2171 5322 122 32311 470pF 10% 100V
2172 4822 126 12263 220pF 10% 2kV
2172 5322 122 32311 470pF 10% 100V
2173 5322 122 32311 470pF 10% 100V
2174 5322 122 32311 470pF 10% 100V
2184 2020 552 96305 4U7 20% 10V
2201 4822 126 14585 100nF 10% 50V
2202 4822 126 14585 100nF 10% 50V
2203 4822 126 14585 100nF 10% 50V
2204 4822 126 14585 100nF 10% 50V
2205 4822 126 14076 220nF 25V
2206 5322 122 32531 100pF 5% 50V
2207 4822 126 13694 68pF 1% 63V
2208 4822 126 14585 100nF 10% 50V
2209 4822 124 40769 4.7mF 20% 100V
2210 4822 124 21913 1mF 20% 63V
2211 4822 126 13482 470nF 80/20% 16V
2213 5322 122 32654 22nF 10% 63V
2214 5322 122 32654 22nF 10% 63V
2215 5322 122 32654 22nF 10% 63V
2216 4822 124 81144 1000mF 16V
2217 5322 122 32654 22nF 10% 63V
2219 4822 126 14076 220nF 25V
2220 4822 121 51252 470nF 5% 63V
2221 5322 122 32654 22nF 10% 63V
2230 4822 124 40769 4.7mF 20% 100V
2234 4822 126 14585 100nF 10% 50V
2238 5322 126 10511 1nF 5% 50V
2239 5322 126 10511 1nF 5% 50V
2240 5322 126 10511 1nF 5% 50V
2241 4822 126 13344 1.5nF 5% 63V
2242 4822 126 14043 1mF 20% 16V
2243 4822 122 33177 10nF 20% 50V
2244 5322 121 42386 100nF 5% 63V
2245 4822 126 14076 220nF 25V
2247 4822 124 81144 1000mF 16V
2248 5322 122 32654 22nF 10% 63V
2249 5322 122 32654 22nF 10% 63V
2250 4822 124 22652 2.2mF 20% 50V
2252 5322 126 10511 1nF 5% 50V
2253 5322 126 10511 1nF 5% 50V
2254 4822 051 20008 Jumper
2330 4822 121 51473 470nF 20% 63V
2340 4822 124 11565 10mF 20% 250V
2341
 4822 126 13599 3.3nF 10% 500V
2342
 5322 122 31647 1nF 10% 63V
2344 4822 051 20008 Jumper
2344 4822 126 14585 100nF 10% 50V
2345
 4822 122 31175 1nF 10% 500V
2346
 4822 126 14237 470pF 10% 2kV
2360 4822 124 40764 22mF 100V
2361 4822 124 40207 100mF 20% 25V
2365 4822 121 40516 22nF 10% 250V
2366 4822 121 40334 100nF 10% 100V
2367 4822 122 33575 220pF 5% 63V
2367 4822 126 13693 56pF 1% 63V
2368 5322 122 32654 22nF 10% 63V
2372 5322 122 32967 5.6pF 10% 63V
2375 5322 122 32531 100pF 5% 50V
2376 4822 126 14585 100nF 10% 50V
2377 4822 126 14585 100nF 10% 50V
2401 4822 124 12438 2.2mF 20% 100V
2401 5322 124 41379 2.2mF 20% 50V
2402
 4822 122 31177 470pF 10% 500V
2404 4822 124 41751 47mF 20% 50V
2405 5322 126 10511 1nF 5% 50V
2420 4822 126 14043 1mF 20% 16V
2421 4822 126 14043 1mF 20% 16V
2421 5322 122 32268 470P 5% 63V
2422 4822 126 14043 1mF 20% 16V
2423 4822 126 14043 1mF 20% 16V
2441 4822 124 21913 1mF 20% 63V
2443 4822 126 13751 47nF 10% 63V
2444 4822 124 21913 1mF 20% 63V
2450 4822 124 11575 47mF 20% 160V
2451 4822 121 41856 22nF 5% 250V
2451 4822 121 51305 15nF 10% 50V
2454 2222 479 90133 68nF 5% 250V
2454 5322 121 40323 100nF 10% 100V
2455 4822 124 40433 47mF 20% 25V
2456 4822 126 14097 680nF 5% 250V
2457
 4822 121 43888 360nF 5% 250V
2457
 4822 126 14096 560nF 5% 250V
2458 4822 124 12438 2.2mF 20% 100V
2459
 4822 126 13185 680pF 10% 500V
2460 5322 122 32531 100pF 5% 50V
2463
 4822 126 11503 820pF 10% 2kV
2463
 4822 126 13435 1.2nF 10% 2kV
2463
 4822 126 14138 680pF 10% 2kV
2464 4822 121 10739 2.2mF 5% 160V
2465
 2222 375 90157 13nF 5% 1.6kV
2465
 4822 121 70618 12nF 5% 1.6kV
2467
 2222 375 90424 9N1 5% 1kV
2467
 2222 375 90429 15nF 5% 1kV
2467 4822 121 40483 10nF 10% 400V
2468
 2222 375 90424 9N1 5% 1kV
2468 5322 121 42532 18nF 10% 400V
2469 4822 126 14097 680nF 5% 250V
2471 5322 121 42386 100nF 5% 63V
2472 4822 121 41854 150nF 5% 63V
2473 5322 121 42386 100nF 5% 63V
2474 4822 122 33127 2.2nF 10% 63V
2475 4822 122 33127 2.2nF 10% 63V
2476 5322 126 10223 4.7nF 10% 63V
2480 5322 121 10472 47mF
2481
 4822 122 31177 470pF 10% 500V
2482 2222 479 90051 120nF 5% 250V
2482 4822 121 40482 68nF 10% 250V
2484 4822 121 10781 470nF 5% 250V
2485 4822 124 12265 4.7mF 20% 250V
2486 2020 021 91577 470mF 20% 16V
2487 4822 124 80604 47mF 20% 50V
2488 4822 124 81145 1000mF 20% 16V
2489 2020 021 91577 470mF 20% 16V
2490 4822 124 12438 2.2mF 20% 100V
2491 4822 122 31175 1nF 10% 500V
2500
 4822 126 13589 470nF 275V
2501
 4822 126 14153 2.2nF 10% 1kV
2502
 4822 126 14153 2.2nF 10% 1kV
2503 4822 124 12415 220mF 20% 400V
2505
 4822 126 14153 2.2nF 10% 1kV
2506 4822 121 70141 33nF 5% 400V
2507 5322 122 34099 470pF 10% 63V
2508 4822 122 50116 470pF 10% 1kV
2509 4822 121 10711 100nF 20% 275V
2515
 4822 126 14049 1.5nF 20% 250V
2516
 4822 126 13867 330P 20% 250V
2520 4822 126 14585 100nF 10% 50V
2521 4822 124 81151 22mF 50V
2522 4822 126 14585 100nF 10% 50V
2523
 4822 126 13862 1.5nF 10% 2kV
2525 5322 122 34099 470pF 10% 63V
2526 4822 126 13482 470nF 80/20% 16V
2527 4822 122 33127 2.2nF 10% 63V
2528 5322 122 31647 1nF 10% 63V
2540 4822 122 33177 10nF 20% 50V
2560 4822 126 14152 680pF 10% 1kV
2561 2020 021 91496 100mF 20% 160V
2562 5322 122 32331 1nF 10% 100V
2563 5322 121 42386 100nF 5% 63V
2564 2020 012 93057 2200mF 20% 16V
2566 4822 124 23432 100mF 20% 10V
2567 4822 124 40433 47mF 20% 25V
2568 4822 124 21913 1mF 20% 63V
2580 4822 124 81286 47mF 20% 16V
2581 4822 124 81151 22mF 50V
2601 4822 126 14076 220nF 25V
2602 5322 122 32531 100pF 5% 50V
2606 5322 126 10511 1nF 5% 50V
2607 5322 122 32659 33pF 5% 50V
2608 4822 126 14043 1mF 20% 16V
2609 5322 122 32659 33pF 5% 50V
2611 4822 126 14043 1mF 20% 16V
2612 4822 126 13694 68pF 1% 63V
2613 4822 126 13694 68pF 1% 63V
2615 5322 126 10511 1nF 5% 50V
2618 4822 126 14043 1mF 20% 16V
2619 4822 126 14043 1mF 20% 16V
2801 4822 124 81151 22mF 50V
2802 4822 126 14076 220nF 25V
2803 2020 552 96305 4U7 20% 10V
2804 2020 552 96305 4U7 20% 10V
2805 2020 552 96305 4U7 20% 10V
2831 5322 122 32447 1pF 5% 63V
