Philips MX5800SA - Page 125

ELECTRICAL PARTS LIST - DAC BOARD
11-12 11-12
RESISTORS
3515 4822 051 30472 4k7 5% 0,062W
3516 4822 051 30472 4k7 5% 0,062W
3517 4822 051 30339 33R 5% 0,062W
3518 4822 051 30103 10k 5% 0,062W
3519 4822 051 30103 10k 5% 0,062W
3520 4822 051 30103 10k 5% 0,062W
3521 4822 051 30103 10k 5% 0,062W
3523 4822 051 30103 10k 5% 0,062W
3667 4822 051 30101 100R 5% 0,062W
4102 4822 051 30008 0R Jumper 0603
4103 4822 051 30008 0R Jumper 0603
4104 4822 051 30008 0R Jumper 0603
4105 4822 051 30008 0R Jumper 0603
4201 4822 051 30008 0R Jumper 0603
4203 4822 051 30008 0R Jumper 0603
4204 4822 051 30008 0R Jumper 0603
4502 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5100 4822 157 71206 Fixed Ind 100MHz 600R
5101 4822 157 71206 Fixed Ind 100MHz 600R
5102 4822 157 71206 Fixed Ind 100MHz 600R
5103 4822 157 71206 Fixed Ind 100MHz 600R
5131 3198 018 61010 Coil 100uH 5%
5132 3198 018 61010 Coil 100uH 5%
5201 3198 018 63390 Coil 33uH 5%
5202 3198 018 63390 Coil 33uH 5%
5211 2422 549 43062 Fixed Ind 100MHz 600R
5212 2422 549 43062 Fixed Ind 100MHz 600R
5213 4822 157 11716 Fixed Ind 100MHz 30R
5214 4822 157 11716 Fixed Ind 100MHz 30R
5501 3198 018 61010 Coil 100uH 5%
5502 3198 018 61010 Coil 100uH 5%
TRANSISTORS & INTEGRATED CIRCUITS
7101 9322 181 11668 MC74VHC04DT
7102 9352 499 80118 74LVC00APW
7111 3198 010 42310 BC847BW
7112 3198 010 42310 BC847BW
7113 3198 010 42310 BC847BW
7151 9322 185 10668 CS8415A-CZ
7201 9322 177 92671 CS4362-KQ
7221 4822 209 30095 LM833D
7222 4822 209 30095 LM833D
7223 4822 209 30095 LM833D
7227 5322 130 44593 BC369
7228 3198 010 42310 BC847BW
7229 9322 190 52668 CS5333-KZ
7501 9337 137 50653 74HCT157D
7502 9322 148 90682 M27C2001-70C1
7503 9351 885 10118 74HCT574PW
7504 9351 885 10118 74HCT574PW
7505 4822 209 17455 74LVC157AD
7506 4822 209 17455 74LVC157AD
7507 3198 010 42310 BC847BW
7508 9322 191 57668 CS492705-CL
7509 3198 010 42310 BC847BW
Note: Only the parts mentioned in this list are normal service
spare parts.
