8-24
8-24
6713 4822 130 11397 BAS316
6714 4822 130 11397 BAS316
6715 4822 130 11397 BAS316
TRANSISTORS & INTEGRATED CIRCUITS
7100 9352 705 74518 TDA8920TH/N1R
7200 9352 705 74518 TDA8920TH/N1R
7300 9352 705 74518 TDA8920TH/N1R
7600 5322 209 11517 PC74HCU04T
7602 5322 130 60159 BC847B
7607 5322 209 14477 HEF4013BT
7608 4822 130 60373 BC857B
7710 5322 130 60159 BC847B
7716 4822 130 60373 BC857B
Note: Only the parts mentioned in this list are normal service
spare parts.
ELECTRICAL PARTS LIST - AMPLIFIER BOARD
DIODES
