12-2 12-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UNIT SCREW LISTS - MAIN UNIT
Breakdown of Satellite LS Package
9965 000 18409 Front Speaker Box Left
MX5800SA
9965 000 19917 Front Speaker Box Left MX5900SA
9965 000 18410 Front Speaker Box Right MX5800SA
9965 000 19918 Front Speaker Box Right MX5900SA
9965 000 18417 Center Speaker Box MX5800SA
9965 000 19924 Center Speaker Box MX5900SA
9965 000 18414 Surr. Speaker Box Left MX5800SA
9965 000 19919 Surr. Speaker Box Left MX5900SA
9965 000 18415 Surr. Speaker Box Right MX5800SA
9965 000 19923 Surr. Speaker Box Right MX5900SA
9965 000 18416 Front/Surround Spk Front Grille Assy
9965 000 18066 Center Spk Grille Assy
9965 000 17046 Philips Logo
9965 000 18067 Base Plate Front/Surround Speaker
9965 000 18068 Mounting Bracket + Screw Pack
Breakdown of Subwoofer Box
Refer to Exploded view on page 12-3
9965 000 18406 2-Pins Terminal
9965 000 18407 Locking Top
9965 000 18413 2-Spring
9965 000 18418 4" Woofer Speaker 8R 100W
9965 000 18411 4-Pins Terminal (White & Purple)
9965 000 18412 4-Pins Terminal (Red & Purple)
9965 000 24208 Supporter with insert nuts
Note: Only the parts mentioned in this list are normal service
spare parts.
MECHANICAL PARTS LIST - LOUDSPEAKERS BREAKDOWN
101 3139 257 50051 Cabinet Front /21R/21S/78
101 3139 257 50041 Cabinet Front /22S
101 3139 257 50811 Cabinet Front /37
102 3139 118 18801 Cover Cab Side Left
103 3139 118 18811 Cover Cab Side Right
105 3139 257 50061 Panel Tray Disc1
106 3139 257 50071 Panel Tray Disc2
107 3139 257 50081 Panel Tray Disc3
108 3139 257 50091 Panel Tray Disc4
109 3139 257 50101 Panel Tray Disc5
110 3139 114 78491 Cover Tray 5DTC MX58/59
120 3139 118 19441 Button Set CD Open/Close
122 3139 113 27511 Cutsheet Shield CD Open/Close
123 3139 257 50111 Panel Left MX5800 /21R/21S/22S
123 3139 257 51701 Panel Left MX5800 /78
123 3139 257 50961 Panel Left MX5900 /37
126 3139 257 50131 Panel Control MX5800
127 3139 118 18871 Button Set Power ECO
128 3139 114 77041 Lightguide Power ECO Standby
133 3139 118 18941 Ring Ornamental
134 3139 118 18931 Cap Knob Rotary Chrome
135 3139 118 18921 Knob Source/Vol Rotary
136 3139 118 19461 Button Set Bass Chrome
137 3139 118 19471 Button Set Treble Chrome
139 3139 257 50121 Panel Display MX5800
140 3139 118 19451 Button Set Source Control
141 3139 118 19481 Ring Ornamental Display
142 3139 114 77551 Lightguide Volume
146 3139 257 51531 Window Display /21R/21S/22S/78
146 3139 114 77531 Window Display /37
148 3139 257 50141 Karaoke Knob /21R/21S/78
256 3139 113 27220 Foot Rubber
259 3139 111 01470 Spring Grounding
261 3139 111 61931 Ground Spring SACD
296 3139 110 40691 Screw Cap Hd Soc Hex Mac M5x6
345 3139 119 00621 Satellite LS Box package
345 3139 119 00671 Satellite LS Box package /37
346 3139 119 00631 Subwoofer Box Stand
346 3139 119 00661 Subwoofer Box Stand
/37
351 4822 303 50063 FM Antenna
352 4822 303 50082 AM Loop Antenna
353 3139 228 61701 Remote Control RC19241001/01
356 2422 070 98151
!
Mains Cord Eur 2A5 1,5M Blk
356 2422 070 98246
!
Mains Cord UL 7A 1,5M Blk /37
357 3139 128 73010
!
AC Adaptor /21S/78
358 4822 263 21206 Cinch Cable 1,7M Yel not for/22S
361 2422 076 00374 Cinch Cable 1,5M RGB not for/22S
362 3103 308 92610 Cinch Cable 1,5M Audio not for/22S
363 2422 076 00528 Scart Cable 21P 1,5M /22S
370 3139 115 22291 Instruction For Use Book /21R/21S
370 3139 115 22311 Instruction For Use Book 1 /37
370 3139 115 22131 Instruction For Use Book 1 /22S
371 3139 115 22561 Instruction For Use Book 2 /22S
1100 3139 119 00831 Function LCD Module MX5500D-01
1110 2822 031 01494 Fan 12Vdc 0,8W 3100rpm
1200 3139 119 00861 Volume LCD Module MX5800SA-01
5001 3139 118 32641
!
Mains Transfo 6x75W /21R/21S/78
5001 3139 118 32651
!
Mains Transformer 6x75W /22S
5001 3139 118 32651
!
Mains Transformer 6x75W /37
8000 3139 110 35031 Flex Cable 8P 14cm AD
8001 3139 111 02001 Flex Cable 13P 40cm BD
8002 3139 111 02461 Flex Cable 14P 40cm AD
8003 3139 111 02211 Flex Cable 16P 10cm AD
8005 3139 111 02051 Flex Cable 7P 34cm AD
8006 4822 320 12751 Flex Cable 4P 40cm AD Non-kara
8006 3139 110 34431 Flex Cable 8P 340cm AD Kara
8008 3139 111 02441 Flex Cable 08P 22cm AD
8010 3139 111 02431 Flex Cable 22P 22cm AD
8010 3139 111 02421 Flex Cable 16P 22cm AD /37
8011 3139 111 02471 Flex Cable 14P 22cm AD
8012 3139 111 02411 Flex Cable 13P 22cm AD
8013 3139 111 02571 Flex Cable 10P 18cm BD
8014 3139 111 02571 Flex Cable 10P 18cm BD
8016 3139 110 36140 Flex Cable 04P 18cm AD
8018 3139 111 02231 Flex Cable 05P 12cm AD
8034 3139 111 02391 Flex Cable 08P 22cm BD
8035 3139 111 02381 Flex Cable 24P 12cm BD
Note: Only the parts mentioned in this list are normal service
spare parts.
185 M3 x 6
186 D3 x 10
190 M3 x 6
191 M3 x 6
192 D3 x 10
193 D3 x 10
228 M3 x 6
229 M3 x 6
231 D3 x 10
232 D3 x 10
233 M3 x 6
235 D3 x 10
236 D3 x 10
276 D3 x 10
277 D3 x 10
278 D3 x 10
279 D2 x 8
280 D2 x 8
281 D2 x 8
282 M3 x 6
283 M3 x 6
284 M3 x 6
285 D3 x 10
286 M3 x 6
287 M3 x 6
288 D3 x 10
289 D3 x 10
290 D3 x 10
291 D3 x 10
292 D3 x 10
293 D3 x 10
295 M3 x 6
296 M5 x 6 Hex W/Head
311 D2 x 8
314 D2 x 8
