9-16 9-16
ELECTRICAL PARTS LIST - AV BOARDELECTRICAL PARTS LIST - AV BOARD
MISCELLANEOUS
1181 2422 026 05399 Socket Aux-in/Digital-In/Out
1182 4822 265 11151 Socket TV-in/Line-out
1183 2422 033 00468 Socket CVBS/S-Video
1184 2422 026 05342 Socket Pr/Pb/Y non-Scart
1186 2422 025 12352 Scart Connector Scart
1187 2422 127 00476 P-Scan Switch except /22S
1230 4822 267 10733 Flex Socket 4P non-Kara
1231 4822 267 10729 Flex Socket 10P
1232 4822 267 10733 Flex Socket 4P
1234 4822 267 10729 Flex Socket 10P
1236 4822 267 10954 Flex Socket 5P
1237 4822 265 11515 Flex Socket 8P
1238 4822 267 10738 Flex Socket 13P
1240 4822 267 51255 Flex Socket 14P
1242 2422 025 16591 Flex Socket 13P
1243 4822 265 11515 Flex Socket 8P Kara
1404 4822 265 11154 Flex Socket 22P
1406 2422 025 17984 Flex Socket 14P
CAPACITORS
2100 3198 016 31020 1nF 25V
2101 3198 016 31020 1nF 25V
2102 2238 586 59812 100nF +80/-20% 50V
2103 2020 552 94427 100pF 5% 50V
2104 2020 552 94427 100pF 5% 50V
2105 3198 017 44740 470nF 10V
2106 3198 017 44740 470nF 10V
2107 2020 552 96327 330nF 10% 16V
2108 4822 126 13879 220nF +80/-20% 16V
2109 2020 552 94427 100pF 5% 50V
2110 5322 126 11579 3,3nF 10% 63V
2111 3198 016 31020 1nF 25V
2112 5322 126 11583 10nF 10% 50V
2113 3198 017 44740 470nF 10V
2114 3198 017 44740 470nF 10V
2115 2020 552 96327 330nF 10% 16V
2116 4822 126 13879 220nF +80/-20% 16V
2117 4822 126 14238 2,2nF 50V
2118 5322 126 11579 3,3nF 10% 63V
2119 3198 016 31020 1nF 25V
2120 5322 126 11583 10nF 10% 50V
2121 3198 017 44740 470nF 10V
2122 2238 916 15641 22nF 10% 25V
2123 4822 124 81151 22uF 50V
2124 4822 124 40196 220uF 20% 16V
2125 4822 126 14238 2,2nF 50V
2126 4822 124 40433 47uF 20% 25V
2127 2020 552 94427 100pF 5% 50V
2128 2020 552 94427 100pF 5% 50V
2129 2238 586 59812 100nF +80/-20% 50V
2130 2238 586 59812 100nF +80/-20% 50V
2136 2238 586 59812 100nF +80/-20% 50V
2139 2238 586 59812 100nF +80/-20% 50V
2143 2238 586 59812 100nF +80/-20% 50V
2144 4822 126 13956 68pF 5% 63V
2145 4822 126 13956 68pF 5% 63V
2150 4822 126 14043 1uF +80/-20% 16V
2151 4822 126 14043 1uF +80/-20% 16V
2152 3198 016 31020 1nF 25V
2153 3198 016 31020 1nF 25V
2154 4822 126 14043 1uF +80/-20% 16V
2155 4822 126 14043 1uF +80/-20% 16V
2156 2020 552 94427 100pF 5% 50V
2157 2020 552 94427 100pF 5% 50V
2160 4822 126 13956 68pF 5% 63V
2161 4822 126 13956 68pF 5% 63V
2162 4822 126 14043 1uF +80/-20% 16V
2163 3198 016 31020 1nF 25V
2164 3198 016 31020 1nF 25V
2165 3198 016 31020 1nF 25V
2166 4822 124 40769 4,7uF 20% 100V
2167 4822 126 14043 1uF +80/-20% 16V
2168 3198 016 31020 1nF 25V
2170 4822 126 14238 2,2nF 50V
2172 3198 017 34730 47nF 16V
2173 3198 017 34730 47nF 16V
2174 3198 017 34730 47nF 16V
2181 4822 126 14472 1uF 10% 10V
2182 4822 126 14472 1uF 10% 10V
2183 4822 126 14472 1uF 10% 10V
2184 4822 126 14472 1uF 10% 10V
2185 4822 126 14043 1uF +80/-20% 16V
2186 4822 126 14043 1uF +80/-20% 16V
2187 2238 586 59812 100nF +80/-20% 50V
2188 2238 586 59812 100nF +80/-20% 50V
2190 2020 552 94427 100pF 5% 50V
2191 2020 552 94427 100pF 5% 50V
2192 2020 552 94427 100pF 5% 50V
2193 2020 552 94427 100pF 5% 50V
2194 2020 552 94427 100pF 5% 50V
2195 2020 552 94427 100pF 5% 50V
2196 2020 552 94427 100pF 5% 50V
2197 2020 552 94427 100pF 5% 50V
2198 2020 552 94427 100pF 5% 50V
2199 3198 017 41050 1uF 10V
Kara
2201 4822 124 40184 1000uF 20% 10V
2202 4822 124 40248 10uF 20% 63V
2207 4822 124 40255 100uF 20% 63V
2208 4822 124 40255 100uF 20% 63V
2209 4822 126 14508 180pF 5% 50V
2210 4822 126 14508 180pF 5% 50V
2211 4822 126 13881 470pF 5% 50V
2212 4822 126 13881 470pF 5% 50V
2213 2020 552 94427 100pF 5% 50V
2214 3198 016 31020 1nF 25V
2215 4822 124 81151 22uF 50V
2216 3198 016 31020 1nF 25V
2217 4822 124 81151 22uF 50V
2218 2020 552 94427 100pF 5% 50V
2219 4822 124 40433 47uF 20% 25V
2220 2238 916 15641 22nF 10% 25V
2224 4822 124 81151 22uF 50V
2225 4822 124 81151 22uF 50V
2226 4822 124 40255 100uF 20% 63V
2227 4822 124 81151 22uF 50V
2231 4822 124 80791 470uF 20% 16V
2232 4822 124 40196 220uF 20% 16V
2233 4822 124 41584 100uF 20% 10V
2240 2020 012 93583 100uF 20% 25V
2241 3198 026 51020 1000uF 20% 50V
2242 4822 124 40433 47uF 20% 25V
2254 3198 017 44740 470nF 10V
2280 3198 017 44740 470nF 10V
2281 3198 017 44740 470nF 10V
2282 3198 017 44740 470nF 10V
2283 3198 017 44740 470nF 10V
2301 3198 017 44740 470nF 10V
2302 3198 017 44740 470nF 10V
2303 2238 586 59812 100nF +80/-20% 50V
2304 3198 017 44740 470nF 10V
2305 2020 552 94427 100pF 5% 50V
2308 2020 552 94427 100pF 5% 50V
2309 4822 126 13193 4,7nF 10% 63V
2310 4822 126 13193 4,7nF 10% 63V
2311 4822 124 40433 47uF 20% 25V
2312 2238 916 15641 22nF 10% 25V
2313 4822 124 40433 47uF 20% 25V
2314 3198 016 31020 1nF 25V
2318 3198 017 44740 470nF 10V
2319 3198 017 44740 470nF 10V
2320 3198 017 44740 470nF 10V
2321 3198 017 44740 470nF 10V
2322 3198 017 44740 470nF 10V
2324 4822 124 12032 4,7uF 20% 50V
2325 2020 552 94427 100pF 5% 50V
2326 3198 017 44740 470nF 10V
2327 2020 552 94427 100pF 5% 50V
2328 2020 552 94427 100pF 5% 50V
2329 2020 552 96684 470nF 10% 25V
2330 4822 126 14472 1uF 10% X7R 0805 10V
2331 4822 126 13193 4,7nF 10% 63V
2332 2020 552 96684 470nF 10% 25V
2333 2222 780 15656 330nF 10% 16V
2334 2222 780 15656 330nF 10% 16V
2335 2020 552 94427 100pF 5% 50V
2336 4822 124 40433 47uF 20% 25V
2337 2238 916 15641 22nF 10% 25V
2338 4822 124 40433 47uF 20% 25V
2339 3198 016 31020 1nF 25V
2340 2020 552 94427 100pF 5% 50V
2341 4822 126 14043 1uF +80/-20% 16V
2342 2238 586 59812 100nF +80/-20% 50V
2343 2020 552 96684 470nF 10% 25V
2344 2020 552 96684 470nF 10% 25V
2349 2238 586 59812 100nF +80/-20% 50V
2351 2020 552 96684 470nF 10% 25V
2352 3198 017 44740 470nF 10V
2353 2238 586 59812 100nF +80/-20% 50V
2381 4822 126 14472 1uF 10% 10V
2390 2020 552 94427 100pF 5% 50V
2391 2020 552 94427 100pF 5% 50V
2392 2020 552 94427 100pF 5% 50V
2393 2020 552 94427 100pF 5% 50V
2394 2020 552 94427 100pF 5% 50V
2395 2020 552 94427 100pF 5% 50V
2396 2020 552 94427 100pF 5% 50V
2397 2020 552 94427 100pF 5% 50V
2400 4822 126 13883 220pF 5% 50V Scart
2401 4822 126 13883 220pF 5% 50V Scart
2402 2238 586 59812 100nF +80/-20% 50V
2403 3198 017 42230 22nF 50V
Scart
2404 4822 126 13883 220pF 5% 50V Scart
2405 4822 126 13193 4,7nF 10% 63V Scart
2406 4822 126 13193 4,7nF 10% 63V Scart
2407 4822 126 13883 220pF 5% 50V
2409 4822 126 13883 220pF 5% 50V
2410 4822 126 13883 220pF 5% 50V
2411 2020 552 94427 100pF 5% 50V
2412 2020 552 94427 100pF 5% 50V
2413 2020 552 94427 100pF 5% 50V
2414 3198 017 41050 1uF 10V Scart
2415 3198 017 41050 1uF 10V Scart
2417 2020 552 94427 100pF 5% 50V
2418 2020 552 94427 100pF 5% 50V
2420 4822 124 40196 220uF 20% 16V
2421 4822 124 40196 220uF 20% 16V
2422 2238 586 59812 100nF +80/-20% 50V
2423 4822 126 14249 560pF 10% 50V
2424 2238 586 59812 100nF +80/-20% 50V
2425 3198 016 31020 1nF 25V
2426 5322 126 11583 10nF 10% 50V
2427 4822 126 14508 180pF 5% 50V
2428 4822 126 11785 47pF 5% 50V
2429 4822 126 14241 330pF 50V
2430 4822 124 40769 4,7uF 20% 100V Scart
2431 4822 126 14043 1uF +80/-20% 16V Scart
2432 4822 126 14043 1uF +80/-20% 16V Scart
2433 3198 016 31020 1nF 25V Scart
