2.2.
REPLACING
PARTS
2.2.1.
Liquid
crystal
display
(fig.
44
item
1),
display
unit
N3 (fig.
44
item
2),
interconnection
rubber
(fig.
44
item
3)
or
function
knob (fig.
44
item
4).
—
Remove
the
front
assembly.
—
Remove
the
six screws
and
the
screening
plate
of
the
front
assembly,
(fig.
44
item
6).
NOTE:
The
potentiometer
R502
can
now
be
removed.
—
Remove
the
function
knob
by bending
out
the
four
hooks
of the
front plate,
(only
for
replacing
the
function
knob)
(fig.
44 item
8).
-
Remove
the
three
screws
from
the
display
unit
cover
and the
cover
itself, (fig.
44 item
5).
—
Replace
the
defective
component
and
mount
the
L.C.D. unit
again
as
described
above.
NOTE
1:
Make
sure
that
the
L
C.D.,
the
display
unit
cover
and the
interconnection
rubber
are
placed
in
the
most right
hand
position,
(fig.
44
item
7).
NOTE 2:
Do
not
touch
the
contacts
of
the
L. C.D.,
the
interconnection
rubber
and
the display
unit
N3
with
the fingers.
2.2.2.
Function
switch,
(fig.
42)
Remove
the
top-
and
bottom
cover.
Remove
also
the front
assembly.
-
Bend
out
the
two
hooks
and
remove
the
printed-circuit
board,
(fig.
42
item
4).
—
The
function
switch
consist
of:
—
2 slide
bodies
—
4
springs
—
4
switch
contacts
—
Remove the
screws
and
nuts
from
the
slide
bodies.
The
bodies can
now
be
lifted
from the
printed-circuit
board.
NOTE:
The
slide
body
is
stocked
complete
with
springs
and
switch
contacts.
2.2.3.
Thermal
fuse
—
Remove
the
bottom
cover.
—
Remove the
four
screws
which
attach
the
screening
plate
of
the
transformer
to the
bottom
cover,
(fig.
45 item
1
).
-
Unsolder
the
black
wire
connecting
the
transformer
with the
screening,
(fig.
45 item
2).
-
Unsolder
the
connections
of
the
thermal
fuse. (fig.
45a. item
1).
-
Replace
the
thermal
fuse
as shown
in fig.
45a.
NOTE:
Do
not
replace
the
thermal
fuse
with
a piece
of wire
as this
gives
the
danger
of
a
fire
hazard.
